Connections
• Connect VIDEO OUT directly to the video input of your
TV. Connecting VIDEO OUT to a TV via a VCR may
interfere with your viewing when playing back copy-
protected discs/files. Connecting VIDEO OUT to an
integrated TV/VCR system may also interfere with your
viewing.
Do not connect the power cord until all other
connections have been made.
Supplied accessories
Check to be sure that you have all the following items.
• FM antenna (x1)
• AM loop antenna (x1)
• Composite video cord (x1)
• Remote control (x1)
• Batteries (x2)
• AC plug adapter (x1)
(not supplied for Australia,
Thailand, Hong Kong region and the Middle East)
If any items are missing, consult your dealer
immediately.
Front panel
From the digital audio player
See page 5.
From the USB mass storage class device
See page 5.
From the headphones
See page 7.
¤ To a wall outlet
Plug in the power cord only after all connections
have been completed.
• If the wall outlet does not match the AC plug, use the
supplied AC plug adapter
(not supplied for
Australia, Thailand, Hong Kong region and the
Middle East) .
! From the digital input of digital audio component
See page 4.
From the powered subwoofer
See page 5.
@ From the input of TV/monitor
See page 5.
~ From AM/FM antenna
See page 4.
Ÿ From the speakers
See page 4.
Rear panel
