10 English
Position of the drive belt - display with removed appliance hood.
Î Loosen the screw on the support plate
Î Slide the support plate down to tension the drive belt
Î Make sure you slide the support plate straight - do not tilt
Î Check the tension of the drive belt, adjust if necessary
Î Tighten all screws on the brush motor support plate.
Î Reinstall the drive belt cover
There is a suction channel cover on the brush head. This channel
can be removed to clean the suction channel.
Î Remove the appliance cover
Î Loosen all 8 screws on the suction channel cover
Î Remove the suction channel cover
Î Clean the suction channel
Î Clean the suction channel seal prior to installation
Î If the seal was damaged during removal, it must be replaced:
Remove the old seal, clean the adhesive surfaces, apply new
seal.
Î Reinstall the suction channel cover
Î Reinstall the appliance hood
5.9 Clean/replace the suction channel
