English 11
The brush rollers must be replaced when the brush length has
reached its tear indication.
Î Tilt the appliance
Î Unlock the latch of the brushes
Î Remove the brush
Î Clean the brush pickup
Î When inserting new brushes, observe the pickups
Î Always replace both brushes
There is a toothed belt in the gears of the brush head, which must
be replaced if damaged.
Î Remove the appliance cover
Î Turn out the 4 screws and remove the gear cover. The
screws are secured with screw adhesive.
Î Loosen tension pulley screw.
Î Fold the tension pulley down
Î Remove toothed belt
Î Insert new toothed belt
Î Fold the tension pulley up (tension toothed belt)
Î Tighten tension pulley screw
Î Reinstall the gear cover
5.10 Replacing the brush rollers 5.11 Replace the toothed belt in the brush head gear
