Kärcher CV 66/2 Service Manual

16 English
8 Technical specifications
Electrical connection
Voltage, EU V 220...240
Frequency Hz 50 - 60
Average power consumption W 1350
Maximum power consumption W 1550
Blower data
Power W 2 x 570
Max. power W 2 x 650
Under-pressure kPa 14,3
Air quantity l/s 2 x 52
Brush
Power W373
Max. power W 400
Drive Gear belt
Working width mm 660
Brush diameter mm 100
Brush speed 1/min 1350
Dimensions and weights
Height mm 1120
Width mm 770
Length mm 1270
Volume of filter bag l 35
Weight kg 72
Noise emission
Sound pressure level (EN 60704-2-1) dB(A) 73
Machine vibrations
Vibration total value (ISO 5349) m/s² 1,5
Power cord
EU: 8.621-716.0 m 22
GB: 8.621-718.0 m 22
AU: 8.621-717.0 m 22
9 Special tools
Description Part number
Not required
10 Tightening torques
Description / Use Tightening torque (Nm)
Plastic screws 6x 5x20, 4x 5x40, 2x 5x80 / screw connection brush housing - bottom part with top
part
0,8
Plastic screws 2x 5x20 / push handle attachment, left 0,8
