Kärcher HD 5 12 User Manual

New Unit Information 02.2004
HD 5/12 Unit functions
Page 3 / 12
View from the front
1 High-pressure hose
2 Handgun
3 Mains connecting plug
4 Spray lance
5 Wheel
6 Triple nozzle.
7 High-pressure connection
8 Water connection with strainer
9 Inspection window for oil level
10 Front cover
11 Unit switch
12 Retaining screw for front cover
13 Handle, height adjustable
4
3
5
6
13
9
8
7
1
11
12
10
2

Kärcher HD 5 12 Specifications

General

Flow Rate	500 l/h
Max Water Flow	500 l/h
Voltage	230 V
Frequency	50 Hz
Pressure	120 bar
