New Unit Information 02.2004
Unit functions
HD 5/12
Page 6 / 12
Electrical box
1
Unit switch
2
Cover
3
Capacitor
4
Connection cable with motor
Electrical box open
–
Pull the retainer clips (arrows) outward and
remove the cover (2).
2
1
3
4
5
7
Table of Contents
Technical Features
2
Unit Functions
3
View from the Front
3
Rear View
4
View from the Front, Cover Removed
5
Electrical Box
6
View from the Rear, Cover Open
7
View from below
8
Motor
9
Cylinder Head
10
Troubleshooting
11
Technical Specifications
12
Special Tool
12
Tightening Torque
12
