New Unit Information 02.2004
Unit functions
HD 5/12
Page 8 / 12
View from below
6
1
2
1
High-pressure connection
2
Pressure switch
3
Cylinder head bolt
4
Suction cover
5
Cylinder head
6
Water connection with strainer
3
4
5
7
