This Instruction Manual describes the control boards F4-C(ompact) and F4-S(mall). It is only valid
together with the Instruction Manuals COMBIVERT F4 Part 1 and Part 2. Both Instruction Manuals must
be made available to the user. Prior to performing any work on the unit the user must familiarize himself
with the unit. This includes especially the knowledge and observance of the safety and warning
directions of Part 1. The pictographs used in this Instruction Manual have following meaning:
Danger Used when life or health of the user are exposed to danger or
Warning when severe damage to the material can occur.
Caution
Attention,
observe at Special instructions for a safe and trouble-free operation.
all costs
Tip
Help Used to mark additional important informations.
Information
The KEB COMBIVERT is operated with voltages that can cause a
severe electric shock dangerous to life. Therefore the installation of
the unit as well as of the available accessories is only permissible by
qualified electro-personnel. A safe and trouble-free operation is only
possible when the valid regulations according to DIN VDE 0100,
IEC1000, EN 60204-1, EN 55014, EN 50082-2 as well as the
relevant regulations for your area are observed.
After clearing the frequency inverter the intermediate circuit capacitors
are still charged with high voltage for a short period of time. The unit
can be worked on again after it has been switched off for 5 minutes.
Attention
Only qualified
Electro-personnel
Danger
Note capacitor
discharge time
