KEB COMBIVERT F4-F Quick Reference

GB-24
Parameter Lists
5. Parameter Lists
5.1 LF-Parameter
‘1 LF.06 = 1 high-resolution on
‘2 LF.04 = 1 SSM
Gr. No. Name Address P E R Resol. Lower Limit Upper Limit Default Value Unit
LF 00 Password 3500 E 1 0 9999 -4 ---
LF 01 User-defined password 3501 E 1 0 9999 440 ---
LF 02 Steering / operating mode 3502 E 1 1 4 1 ---
LF 04 ASM/SSM-selection 3504 E 1 0:ASM 1:SSM 0:ASM ---
LF 05 Reversal of travel direction 3505 1 0:off 1:on 0:off ---
LF 06 High-resolution 3506 E 1 0:off 1:on 0:off ---
LF 19 DC voltage compensation 3513 E 1 150 501:off 400 V
LF 20 Rated system speed 3514 0,001 0,000 15,000 0 m/s
LF 21 Traction sheave diameter 3515 1 200 2000 600 mm
LF 22 Gear reduction ratio 3516 0,01 1,00 99,99 30 ---
LF 23 Catenary suspension 3517 1 1 8 1 ---
LF 24 Load 3518 1 0 65535 0 kg
LF 25 Torque increase of the door drive 3519 0,1 0,0 25,5 6 %
LF 26 Rated speed of the door drive 351A 1 100 6000 1440 rpm
LF 27 Rated frequency of the door drive 351B 1 20 100 50 Hz
LF 28 Rated voltage of the door drive 351C 1 1 650 400 V
LF 30 Control method 351E E 1 0 3 0 ---
LF 31 KP speed 351F 1 1 65535 3000 ---
LF 32 KI speed 3520 1 0 65535 1000 ---
LF 33 KI speed offset 3521 1 0 65535 1000 ---
LF 34 KP current 3522 1 1 65535 1500 ---
LF 35 KI current 3523 1 0 65535 500 ---
LF 36 Maximum torque 3524 0,1 0 dr.10 2 * dr.9
1'1 1,5*dr.9 '2 Nm
LF 37 Torque increase 3525 0,1 0,0 25,2 10 %
LF 38 Operating frequency change 3526 1 0 1 1 ---
LF 40 Set value VB, correction speed 3528 0,001 0,000 0,300 0 m/s
LF 41 Set value VE, crawl speed 3529 0,001 0,000 0,300 0 m/s
LF 42 Set value VN, rated speed 352A 0,001 0,000 LF.20 0 m/s
LF 43 Set value VI, inspection speed 352B 0,001 0,000 0,630 0 m/s
LF 44 Set value V1, intermediate speed 1 352C 0,001 0,000 LF.20 0 m/s
LF 45 Set value V2, intermediate speed 2 352D 0,001 0,000 LF.20 0 m/s
LF 46 Set speed of door drive 352E 0,5 0 16000 0 rpm
0,1 '1 2000 '1
LF 50 Starting jerk 3532 0,01 0,10 9,99 0,60 m/s^3
LF 51 Acceleration 3533 0,01 0,10 2,00 0,90 m/s^2
LF 52 Deceleration jerk 3534 0,01 0,10 9,99 1,00 m/s^3
LF 53 Deceleration 3535 0,01 0,10 2,00 0,60 m/s^2
LF 54 Stopping jerk 3536 0,01 0,01:off 9,99 0,01:off m/s^3
LF 55 Starting jerk VE (crawl speed) 3537 0,01 0,10 9,99 0,60 m/s^3
LF 56 Acceleration VE (crawl speed) 3538 0,01 0,10 2,00 0,90 m/s^2
LF 57 Speed Deviation mode 3539 1 0 2 1 ---
LF 58 Speed deviation level 353A 1 0 30 10 %
LF 59 Speed diviation - release time 353B 0,001 0,000 10,000 3,000 s
LF 60 Switching level brake disconnection 353C 0,001 0,000 0,010 0,005 m/s
LF 61 Monitoring overspeed 353D 0,001 0,000 18,000 1,1 * LF.42 m/s
LF 62 Deceleration check level 353E 0,001 0,000 15,000 0,95 * LF.42 m/s
LF 63 Running open door level 353F 0,001 0,000 0,300 0,250 m/s
