KEB COMBIVERT F4-F Quick Reference

GB-5
Inputs / Outputs
1.2 Terminal X3 I/O-Expander (units > G-housing)
Terminal Function
1 Digital input signal: contactor control (see chapter 3.6) max. voltage endurance to ground: 100 V
2 Setpoint input correction-speed: V
B
digital inputs for setpoint activation
3 Setpoint input positioning speed: V
E
! only valid with LF.2 = 2 !
4 Setpoint input rated speed: V
N
max. voltage endurance to ground: 100 V
5 Setpoint input inspection speed: V
I
6 Setpoint input intermediate speed 1: V
1
terminal assignment with binary coded
7 Setpoint input intermediate speed 2: V
2
set value selection see LF.2
8 Option ! do not connect !
9 + 24 ... + 30 V external voltage input
External supply voltage
10 for relay outputs on terminal X3
11
Ground for X3.9 / X3.10
12
13 Output signal: ready / overspeed ≈ U
X3.9 / X3.10
/ 500 mA see chapter 3.4
14 Output signal: switching frequency warning ≈ U
X3.9 / X3.10
/ 500 mA see chapter 3.4
15
Output relay contact: braking control 30 V DC / 1 A see chapter 3.4
16
17 Output signal: delay control ≈ U
X3.9 / X3.10
/ 500 mA see chapter 3.4
18
Output relay contact: running open doors 30 V DC / 1 A see chapter 3.4
19
20
Output relay contact: main contactor control 30 V DC / 1 A see chapter 3.4
21
22 Output signal: DC monitoring ≈ U
X3.9 / X3.10
/ 500 mA see chapter 3.4
23 Output signal: motor temperature warning ≈ U
X3.9 / X3.10
/ 500 mA see chapter 3.4
