Parameter Lists
5.3 EC-Parameter
5.4 An-Parameter
Gr. No. Name Address P E R Resol. Lower Limit Upper Limit Default Value Unit
An 01 Noise filter analog inputs 2801 Tab 0 8 3 ---
An 02 Zero point hysteresis REF 1 2802 0,1 0,0 10,0 0,2 %
An 03 REF 1 gain 2803 0,01 -20,00 20,00 1,00 ---
An 04 REF 1 Offset X 2804 0,1 -100,0 100,0 0,0 %
An 05 REF 1 Offset Y 2805 0,1 -100,0 100,0 0,0 %
An 08 Zero point hysteresis REF 2 2808 0,1 0,0 10,0 0,2 %
An 09 REF 2 gain 2809 0,01 -20,00 20,00 1,00 ---
An 10 REF 2 Offset X 280A 0,1 -100,0 100,0 0,0 %
An 11 REF 2 Offset Y 280B 0,1 -100,0 100,0 0,0 %
An 13 REF 2 Funktion 280D E 1 0 7 7 ---
An 14 Analog output 1 function 280E E 1 0 6 4 ---
An 15 Analog output 1 gain 280F 0,01 -20,00 20,00 1,00 ---
An 16 Analog output 1 offset X 2810 0,1 -100,0 100,0 0,0 %
An 18 Analog output 2 function 2812 E 1 0 6 0 ---
An 19 Analog output 2 gain 2813 0,01 -20,00 20,00 1,00 ---
An 20 Analog output 2 offset X 2814 0,1 -100,0 100,0 0,0 %
Gr. No. Name Address P E R Resol. Lower Limit Upper Limit Default Value Unit
EC 00 Encoder interface 1 3800 R 1 ---
EC 01 Pulse number encoder 1 3801 E 1 256 10000 2500 Inc
EC 02 Track change encoder 1 3802 1 0 : off 1 : on 0 : off ---
EC 03 Encoder pole pairs 3803 1 0 : off 1 : on 0 : off ---
EC 04 System position adjustment 3804 1 0 7 0 ---
EC 05 Clock frequency encoder 1 3805 E 0,01 5,00 10,00 8,00 kHz
EC 06 Encoder 1 mode 3806 E 1 0 1 0 ---
EC 07 System position E 1 0 65535 19017 ---
EC 08 Speed sampling time encoder 1 3808 1 0 5 3 ---
EC 09 Current input resolver 3809 E 0,1 -1:Auto 72,0 7,7 mA
EC 10 Encoder interface 2 380A R 1 --- --- --- ---
EC 11 Pulse number encoder 2 380B E 1 256 10000 2500 Inc
EC 17 Divider incremental encoder output 3811 E 1 0 : off 1 : on 0 : off ---
EC 20 Hiper-Type 3814 R 1 ---
EC 21 Hiper-Status 3815 R 1 ---
EC 22 Read Hiperface data 3816 1 0 1 0 ---
EC 23 Write Hiperface data 3817 1 0 1 0 ---
