ANTRIEBSTECHNIK
GB 61
GB
10.3 Parameter list
Para. Name Address E R Res. Lower
Limit
Upper
Limit
Default Unit
LF.00 Password 3500 E 1 0 9999 -4 -
LF.01 User-Defined Password 3501 E 1 0 9999 440 -
LF.02 Steering/Operating Mode 3502 E 1 1 4 1 -
LF.03 Divider Incremental Encoder Output 3503 1 1 128 1 -
LF.04 ASM / SSM - Selection 3504 E 1 0 1 0 -
LF.05 Reverse Direction of Travel 3505 1 0 1 0 -
LF.10 ASM-Rated Motor Power 350A 0,01 0,00 75,00 4,00 kW
LF.11 ASM-Rated Motor Speed 350B 1 100 6000 1440 rpm
LF.12 ASM-Rated Motor Current 350C 0,1 1,0 1,1*Inv 8,0 A
LF.13 ASM-Rated Motor Frequency 350D 1 20 100 50 Hz
LF.14 ASM-Rated Motor Voltage 351E 1 1 650 400 V
LF.15 ASM-Power Factor 351F 0,01 0,01 1,00 0,86 -
LF.16 Field Weakening Speed 3510 0,1 0,0 6000,0 1200,0 rpm
LF.17 ASM-Encoder Pulse Number 3511 1 256 10000 2500 Imp/U
LF.18 ASM-Encoder Track 3512 E 1 0 1 0 -
LF.19 DC Voltage Compensation 3513 E 1 150 500 400 V
LF.20 Rated System Speed 3514 0,001 0,000 15,000 0,000 m/s
LF.21 Traction Sheave Diamter 3515 1 200 2000 600 mm
LF.22 Gear Reduction Ratio 3516 0,01 1,00 99,99 30,00 -
LF.23 Catenary Suspension 3517 1 1 8 1 -
LF.24 Load 3518 1 0 65535 0 kg
LF.25 Torque Increase of the Door Drive 3519 0,1 0,0 25,5 6,0 %
LF.26 Rated Speed of the Door Drive 351A 1 100 6000 1440 rpm
LF.27 Rated Frequency of the Door Drive 351B 1 20 100 50 Hz
LF.28 Rated Voltage of the Door Drive 351C 1 1 650 400 V
LF.30 Control Method 351D E 1 0 3 0 -
LF.31 ASM- KP Speed 351E 1 1 65535 3000 -
LF.32 ASM- KI Speed 3520 1 1 65535 1000 -
LF.33 ASM- KI Speed Offset 3521 1 0 65535 1000 -
LF.34 ASM- KP Current 3522 1 1 65535 1500 -
LF.35 ASM- KI Current 3523 1 1 65535 500 -
LF.36 ASM-Maximum Torque 3524 0,1 0,0 5*Mn 2*Mn Nm
LF.37 Boast 3525 0,1 0,0 25,5 10,0 %
LF.38 Operating Frequency Change 3526 1 0 1 1 -
LF.40 Correction Speed 3528 0,001 0,000 0,300 0,000 m/s
LF.41 Crawl Speed 3529 0,001 0,000 0,300 0,000 m/s
LF.42 Rated Speed 352A 0,001 0,000 LF.20 0,000 m/s
LF.43 Inspection Speed 352B 0,001 0,000 0,630 0,000 m/s
LF.44 Intermediate Speed 1 352C 0,001 0,000 LF.20 0,000 m/s
LF.45 Intermediate Speed 2 352D 0,001 0,000 LF.20 0,000 m/s
LF.46 Set Speed of Door Drive 352E 0,1 0,0 3000,0 0,0 rpm
LF.50 Starting Jerk 3532 0,01 0,11 9,99 0,60 m/s^3
LF.51 Acceleration 3533 0,01 0,10 2,00 0,90 m/s^2
LF.52 Deceleration Jerk 3534 0,01 0,11 9,99 1,00 m/s^3
LF.53 Deceleration 3535 0,01 0,10 2,00 0,90 m/s^2
LF.54 Stopping Jerk 3536 0,01 0,02 9,99 off m/s^3
LF.60 Level Brake 353C 0,001 0,000 0,010 0,005 m/s
LF.61 Level Overspeed 353D 0,001 0,000 18,000 1,500 m/s
LF.62 Deceleration Check 353E 0,001 0,000 15,000 1,300 m/s
LF.63 Level Crawl Speed 353F 0,001 0,000 0,300 0,250 m/s
LF.64 DC-Voltage Circuit Control 3540 1 0 800 0 V
LF.65 "E.dOH"-Delay 3541 1 0 3600 300 s
LF.66 Heat Sink Temperature Level 3542 1 20 50 40 °C
10. Supplement
