GB - 19
3.6 Control board Multi/Servo/Application with encoder interface
3.6.1 X2A Control Terminal Strip
Tightening torque 0.22…0.25 Nm (2 lb inches) X2A
Use shielded/drilled cables
123456789
10 11 12 13 14 15 16 17 18 19 20 21
22 23 24 25 26 27 28 29
Lay shield on one side of the inverter onto earth
potential
PIN Function Name Description
Differential voltage input 0…±10 V DC; Ri = 55 kΩ
1 + Setpoint input 1 AN1+ Setting of the analog setpoint at vector controlled opera-
tion (CP.10=4) 0…±CP.28
2 - Setpoint input 1 AN1-
3 +Analog input 2 AN2+ Setting of the analog setpoint at torque-controlled opera-
tion (CP.10=5; CP.28=1) 0…±100 %
4 -Analog input 2 AN2-
Programmable analog outputs 0…±10 V DC (max. 5 mA)
5 Analog output 1 AO1 Output speed 0…±3000
min-1
6 Analog output 2 AO2 Apparent current 0…2•Inominal
7 +10V output CRF Reference voltage for setpoint poti
+10 V DC / max. 4 mA
8
Analog ground COM Ground for analog in- and output
9
Programmable digital inputs 13…30 V DC ±0 % smoothed Ri: 2.1 kΩ; scan time: 2 ms
10 Fixed speed 1 (CP.23) I1 Selection of xed speeds; I1+I2 = xed speed 3;
no input = analog set value
11 Fixed speed 2 (CP.24) I2
12 External fault I3 Input for external error setting (E.EF)
13 I4 no function in the CP-Mode
14 Limit switch right F
Limit switch
15 Limit switch left R
16 Control release / Reset ST Power modules are enabled; reset at opening
17 Reset RST Reset; only when an error occurs
Digital outputs I = max. 50 mA
18 Transistor output 1 O1 Switched at real value = setpoint value
19 Transistor output 2 O2 Ready signal - switched as long as no error occurs
20 24 V - output Uout Supply of the digital inputs (24 V DC/ max. 100 mA)
21 20…30 V - input Uin Voltage input for external supply
22
Digital ground 0V Reference potential for digital inputs/outputs
23
Relay outputs Load capacity max. 30 V DC / 0.01…1 A
24 Relay 1 / NO contact RLA
Programmable relay output (CP.33)
Factory setting: Fault relay
25 Relay1 / NC contact RLB
26 Relay1 / switching
contact
RLC
27 Relay 2 / NO contact FLA
Programmable relay output (CP.34)
Factory setting: Run signal
28 Relay 2 / NC contact FLB
29 Relay 2 / switching
contact
FLC
