KEB COMBIVERT F5 Series Installation Manual

GB - 30
CP-Parameter
5.2 Parameter description for Multi and Application with encoder interface
Display Parameter Setting range Resolution Default Unit ENTER Based on
CP.00 Password Input 0...9999 1 – – – ud.01
CP.01 Encoder 1 speed ±4000 0.125 0 rpm – ru.09
CP.02 Setpoint display ±4000 0.125 0 rpm – ru.01
CP.03 Inverter state 0...255 1 0 – – ru.00
CP.04 Apparent current 0...6553.5 0.1 0 A – ru.15
CP.05 Apparent current / peak value 0...6553.5 0.1 0 A – ru.16
CP.06 Actual torque ±10000.00 0.01 0 Nm – ru.12
CP.07 Actual DC voltage 0...1000 1 0 V – ru.18
CP.08 DC-link voltage / peak value 0...1000 1 0 V – ru.19
CP.09 Output voltage 0...778 1 0 V – ru.20
CP.10 Speed control conguration 0(off)...5 1 0 (off) – – cs.00
CP.11 DASM Rated speed 0...32000 1 LTK rpm – dr.24
CP.12 DASM rated frequency 0.0...1600.0 0.1 LTK Hz – dr.25
CP.13 DASM rated current 0.0...1100.0 0.1 LTK A – dr.23
CP.14 DASM Rated voltage 120...830 1 LTK V – dr.02
CP.15 DASM Rated cos (phi) 0.50...1.00 0.01 LTK – – dr.04
CP.16 DASM Rated power 0.10...1000.00 0.01 LTK kW – dr.03
CP.17 Load motor dependent parameter 0...3 1 1 – E fr.10
CP.18 Boost 0.0...25.5 0.1 LTK % – uf.01
CP.19 rated frequency 0...400 0.0125 50 Hz – uf.00
CP.20 Encoder 1 (inc/r) 1…65535 1 2500 Inc E ec.01
CP.21 Encoder 1 rotation 0...19 1 0 – E ec.06
CP.22 Maximum speed 0...4000 0.125 2100 rpm – op.10
CP.23 Step value 1 ±4000 0.125 100 rpm – op.21
CP.24 Step value 2 ±4000 0.125 -100 rpm – op.22
CP.25 Acceleration time 0.00...300.00 0.01 5,00 s – op.28
CP.26 Deceleration time -0.01...300.00 0.01 5,00 s – op.30
CP.27 S-curve time 0.00(off)...5.00 0.01 0.00(off) s – op.32
CP.28 Torque reference source 0...6 1 2 – E cs.15
CP.29 Absolute torque reference ±32000,00 0.01 LTK Nm – cs.19
CP.30 KP speed 0...32767 1 300 – – cs.06
CP.31 KI speed 0...32767 1 100 – – cs.09
CP.32 Switching frequency 1...LTK 1 LTK – E uf.11
CP.33 Relay output 1 / Function 0...92 1 4 – E do.02
CP.34 Relay output 2 / Function 0...92 1 2 – E do.03
CP.35 Limit switch / stopping mode 0...6 1 6 – – pn.07
CP.36 External Fault / stopping mode 0...6 1 0 – – pn.03
CP.3 Inverter status
In parameter „inverter status“ the actual operating condition of the frequency inverter is
displayed (e.g. constant running forward, standstill). In the case of an error the current error
message is displayed, even if the display has already been reset with ENTER (error-LED
on the operator is still blinking). Status messages and information about the cause and
removal are to be found in "www.keb.de".
