KEB COMBIVERT F5 Original Manual

Technical Data
14
©
2020 KEB America, Inc.
4 Technical Data
4.1 Operating Conditions
4.1.1 Climatic Environment Conditions
Storage
Standard
Class
Descriptions
Surrounding temperature
EN 60721-3-1
1K4
-25 to 55 °C
Relative humidity
EN 60721-3-1
1K3
5 to 95 % (without condensation)
Storage height
–
–
Max. 3000 m above sea level
Transport
Standard
Class
Descriptions
Surrounding temperature
EN 60721-3-2
2K3
-25 to 70 °C
Relative humidity
EN 60721-3-2
2K3
95 % at 40 °C (without condensation)
Operation
Standard
Class
Descriptions
Surrounding temperature
EN 60721-3-3
3K3
-10 to 45 °C (extended from 5 to 40 °C)
Relative humidity
EN 60721-3-3
3K3
5 to 85 % (without condensation)
Version and degree of
protection
EN 60529
IP20
Protection against foreign material > ø12.5 mm
No protection against water
Non-conductive pollution, occasional
condensation when the unit is out of service.
Site altitude – – Max. 2000 m above sea level
Table 1: Climatic environment conditions
4.1.2 Mechanical Ambient Conditions
Storage
Standard
Class
Description
Vibration limits
EN 60721-3-1
1M1
Vibration amplitude 0.3 mm (2 to 9 Hz)
Acceleration amplitude 1 m/s2 (9 to 200 Hz)
Shock limit values EN 60721-3-1 1M1 40 m/s2, 22 ms
Transport Standard Class Description
Vibration limits EN 60721-3-2 2M1 Vibration amplitude 3.5 mm (2 to 9 Hz)
Acceleration amplitude 10 m/s2 (9 to 200 Hz)
(Acceleration amplitude 15 m/s2 (200 to 500
Hz))
Shock limit values EN 60721-3-2 2M1 100 m/s2, 11 ms
Operation
Standard
Class
Description
Vibration limits
EN 60721-3-3
3M4
Vibration amplitude 3.5 mm (2 to 9 Hz)
Acceleration amplitude 10 m/s2 (9 to 200 Hz)
EN 61800-5-1 Vibration amplitude 0.075 mm (10 to 57 Hz)
Acceleration amplitude 10 m/s2 (57 to 150 Hz)
Shock limit values
EN 60721-3-3
3M4
100 m/s2
Table 2: Mechanical ambient conditions
