KEB COMBIVERT F5 Original Manual

Technical Data
16
©
2020 KEB America, Inc.
4.2 Rated Values
Characteristic
Value
Supply Voltage 24V (18 to 30V)
Supply Current 10mA @ 24VDC
Contact Rating (K1 / K2 Pilot Duty
2A DC Maximum 30VDC
2A AC Maxiumum 120VAC
Monitor Input
BR+ / BR-
350 to 800VDC
840VDC maximum
On time to trigger contact state change >64ms
Table 5: Rated values
i
 If the control voltage applied to contacts K1 and K2 is 120VAC, the
safe insulation between the 24VDC supply and the contacts K1/K2 is
reduced to basic insulation.
As a result the entire 24V control circuit of
the drive is reduced to basic insulation according to UL61800-5-1.
