6.2.2
External fan power supply
+
-
➁
T
erminal strip
Only internal use
➁
External fan power supply
T
erminals
V
oltage supply
+, -
DC
24 V ±10 %
Current draw per module
Spare fuse(s)
2.5 A
or
4 A
3.15 A
T
ype
gG
Cable cross-section
Maximum tightening torque
mm²
A
WG/MCM
Nm
lb inch
4
10
0.6
5.3
Figure 18:
External fan power supply
66
ELECTRICAL
INST
ALLA
TION
65
67
