KEB COMBIVERT F6 User Manual

Table I Branch Circuit Protection of inverter series F5 / F6 – P – housing:
a)ClassJorRK5Fusesasspeciedbelow:
Inverter F5/F6 Input Voltage [V] UL 248 Fuse type J or RK5 [A]
28 480 / 3ph 3x400
29 480 / 3ph 3x500
29 480 / 3ph 2 x 3x300
30 480 / 3ph 3x600
30 480 / 3ph 2 x 3x350
32 480 / 3ph 2 x 3x400
32 480 / 3ph 3 x 3x300
33 480 / 3ph 2 x 3x450
33 480 / 3ph 3 x 3x350
34 480 / 3ph 2 x 3x500
34 480 / 3ph 3 x 3x400
35 480 / 3ph 2 x 3x600
35 480 / 3ph 3 x 3x400
36 480 / 3ph 3 x 3x500
37 480 / 3ph 3 x 3x600
38 480 / 3ph 3 x 3x600
Table 31: UL fuses
b)InverseTimeCircuitBreakerasspeciedbelow:
Inverter Input Voltage [V] UL 489 MCCB [A] Siemens Cat. No.
28 480 / 3ph 400 3VL400/JG-frame
29 480 / 3ph 600 3VL400X/LG-frame
29 480 / 3ph 2 x 400 2x 3VL400/JG-frame
30 480 / 3ph 600 3VL400X/LG-frame
30 480 / 3ph 2 x 400 2x 3VL400/JG-frame
32 480 / 3ph 2 x 400 2x 3VL400/JG-frame
32 480 / 3ph 3 x 400 3x 3VL400/JG-frame
33 480 / 3ph 2 x 600 2x 3VL400X/LG-frame
33 480 / 3ph 3 x 400 3x 3VL400/JG-frame
34 480 / 3ph 2 x 600 2x 3VL400X/LG-frame
34 480 / 3ph 3 x 400 3x 3VL400/JG-frame
35 480 / 3ph 2 x 600 2x 3VL400X/LG-frame
35 480 / 3ph 3 x 400 3x 3VL400/JG-frame
36 480 / 3ph 3 x 500 3x 3VL400X/LG-frame
37 480 / 3ph 3 x 600 3x 3VL400X/LG-frame
38 480 / 3ph 3 x 600 3x 3VL400X/LG-frame
Table 32: Cable protection switch
94
CERTIFICATION
