KEB COMBIVERT F6 User Manual

In order to comply with CSA C22.2 No. 14-2010 (cUL) following external Filters and
Mains Chokes manufactured by KEB Automation KG need to be installed:
Voltage class
Inverter size /
Mod.
Filter Mains choke Alt. Choke
400 / 480 V
28/1 1 x 28E4T60-1001 1 x 28Z1B04-1000 28Z1B05-1002
29/1 1 x 30E4T60-1001 1 x 29Z1B04-1000 29Z1B05-1002
29/2 2 x 26E4T60-1001 2 x 25Z1B04-1000 25Z1B05-1002
30/1 1 x 30E4T60-1001 1 x 30Z1B04-1000 30Z1B05-1002
30/2 2 x 26E4T60-1001 2 x 27Z1B04-1000 27Z1B05-1002
32/2 2 x 28E4T60-1001 2 x 28Z1B04-1000 28Z1B05-1002
32/3 3 x 26E4T60-1001 3 x 25Z1B04-1000 25Z1B05-1002
33/2 2 x 28E4T60-1001 2 x 28Z1B04-1000 28Z1B05-1002
33/3 3 x 26E4T60-1001 2 3 27Z1B04-1000 27Z1B05-1002
34/2 2 x 30E4T60-1001 2 x 29Z1B04-1000 29Z1B05-1002
34/3 3 x 26E4T60-1001 2 3 27Z1B04-1000 27Z1B05-1002
35/2 2 x 30E4T60-1001 2 x 30Z1B04-1000 30Z1B05-1002
35/3 3 x 28E4T60-1001 3 x 28Z1B04-1000 28Z1B05-1002
36/3 3 x 28E4T60-1001 3 x 28Z1B04-1000 28Z1B05-1002
37/3 3 x 30E4T60-1001 3 x 29Z1B04-1000 29Z1B05-1002
38/3 3 x 30E4T60-1001 3 x 30Z1B04-1000 30Z1B05-1002
Table 30: External lters and chokes
Detailed wiring Instructions for the external Filters and Mains Chokes
as speci󰘰ed are present in the Installation Instructions of the products.
Short Circuit rating and Branch Circuit Protection:
All 480 V Models:
Suitable For Use On A Circuit Capable Of Delivering Not More Than 100 kA rms Sym-
metrical Amperes, 480 Volts Maximum when Protected by Class J or RK5 Fuses, rated
___ Amperes
or when Protected by A Circuit Breaker Having an Interrupting rating Not Less than
100 kA rms Symmetrical Amperes, 480 V maximum, rated ___ Amperes
93
CERTIFICATION
