3
BASICS
To Do this (on the faceplate) Do this (on the remote control)
Turn on the power Press L SRC.
• Press and hold to turn off the power.
Press and hold SRC to turn off the power.
( Pressing SRC does not turn on the power. )
Adjust the volume Turn the volume knob. Press VOL
or VOL .
Press ATT during playback to attenuate the sound.
• Press again to cancel.
Select a source Press L SRC repeatedly. Press SRC repeatedly.
Change the display
information
Press SCRL DISP repeatedly.
• Press and hold to scroll the current display information.
( not available )
Faceplate
How to reset
Attach
Detach
Remote control (RC-406)
Volume knob
(turn/press) Loading slot
Detach button Display window
ENGLISH |
Pull out the
insulation sheet
when using for
the first time.
Your preset adjustments
will also be erased.
How to replace the battery
* Not used.
Remote sensor (Do not expose
to bright sunlight.)
EN_KDC-105U[K0]2.indd 3EN_KDC-105U[K0]2.indd 3 8/9/12 9:22:16 AM8/9/12 9:22:16 AM
