8
AUDIO SETTINGS
While listening to any source...
1 Press AUDIO to select
[AUD CTRL]
.
2 Turn the volume knob to make a selection (see the table below), then press the knob.
Repeat step 2 until the desired item is selected or activated.
3 Press and hold to exit.
• To return to the previous hierarchy, press .
Default:
XX
SW LEVEL –15 to +15 (0): Adjusts the subwoofer output level.
BASS LVL
–8 to +8 (0):
Adjusts the level to memorize for each source. (Before making an adjustment,
select the source you want to adjust.)
MID LVL
–8 to +8 (0):
TRE LVL
–8 to +8 (0):
EQ
NATURAL/ USER/ ROCK/ POPS/ EASY/ TOP40/ JAZZ/ POWERFUL: Selects a preset equalizer
suitable to the music genre. (Select [USER] to use the customized bass, middle, and treble settings.)
B. BOOST
BB-L LV1/ BB-L LV2/ BB-L LV3
: Selects your preferred bass boost level. ;
BB-L OFF
: Cancels.
LOUDNESS
LOUD LV1/ LOUD LV2: Selects your preferred low and high frequencies boost to produce a well-
balanced sound at a low volume level. ; LOUD OFF: Cancels.
BALANCE
BAL L15 to BAL R15 (0): Adjusts the left and right speaker output balance.
FADER
FAD R15 to FAD F15 (0): Adjusts the rear and front speaker output balance.
SW SET
SW ON: Turns on the subwoofer output. ; SW OFF: Cancels.
DTIL SET
LPF SW
LPF THRU: All signals are sent to the subwoofer. ;
LPF
85H/
LPF
120H/
LPF
160H: Audio signals with
frequencies lower than 85 Hz/ 120 Hz/ 160 Hz are sent to the subwoofer.
SW PHASE PHAS REV (180°)/ PHAS NML (0°): Selects the phase of the subwoofer output to be in line with
the speaker output for optimum performance. (Selectable only if a setting other than [LPF THRU] is
selected for [LPF SW].)
SPRM SET
SPRM ON: Creates realistic sound by interpolating the high-frequency components that are lost in
MP3/WMA audio compression. ; SPRM OFF: Cancels. (Selectable only when playing back an MP3/
WMA disc or a USB device.)
V-OFFSET
(Default: 0)
–8 to +8 (for AUX) ; –8 to 0 (for other sources): Presets the volume adjustment level of each source.
(Before adjustment, select the source you want to adjust.)
•
[SW LEVEL]
/
[SW SET]
/
[LPF SW]
/
[SW PHASE]
is selectable only if
[SWPRE]
is set to
[SWPRE SW]
. (➜
4
)
•
[SW LEVEL]
/
[LPF SW]
/
[SW PHASE]
is selectable only if
[SW SET]
is set to
[SW ON]
.
MORE INFORMATION
General
• This unit can only play the following CDs:
• Detailed information and notes about the playable audio files are stated in an
online manual on the following site: www.kenwood.com/cs/ce/audiofile/
Playable files
• Playable Audio file: MP3 (.mp3), WMA (.wma)
• Playable disc media: CD-R/RW/ROM
• Playable disc file formats: ISO 9660 Level 1/2, Joliet, Romeo, Long file name.
• Playable USB device file system: FAT16, FAT32
Although the audio files are complied with the standards listed above, playback
maybe impossible depending on the types or conditions of media or device.
Unplayable discs
• Discs that are not round.
• Discs with coloring on the recording surface or discs that are dirty.
• Recordable/ReWritable discs that have not been finalized.
• 8 cm CD. Attempting to insert using an adapter may cause malfunction.
About USB devices
• This unit can play MP3/WMA files stored on a USB mass storage class device.
• You cannot connect a USB device via a USB hub and Multi Card Reader.
• Connecting a cable whose total length is longer than 5 m may result in abnormal
playback.
• This unit cannot recognize a USB device whose rating is other than 5 V and exceeds
1 A.
About “KENWOOD Music Editor Light” and “KENWOOD Music
Control”
• This unit supports the PC application “KENWOOD Music Editor Light” and Android™
application “KENWOOD Music Control.”
• When you use an audio file with database information added using the “KENWOOD
Music Editor Light” or “KENWOOD Music Control,” you can search for a file by title,
album or artist name using Music Search.
• “KENWOOD Music Editor Light” and “KENWOOD Music Control” are available from
the following web site: www.kenwood.com/cs/ce/
EN_KDC-105U[K0]2.indd 8EN_KDC-105U[K0]2.indd 8 8/9/12 9:22:20 AM8/9/12 9:22:20 AM
