Kenwood KMM-BT304 User Manual

12
ENGLISH
BLUETOOTH — Connection
Supported Bluetooth profiles
– Hands-Free Profile (HFP)
– Advanced Audio Distribut ion Profile (A2DP)
– Audio/Video Remot e Control Profile (AVRCP)
– Serial Port Profile (SPP)
– Phonebook Access Profile (PBAP)
Supported Bluetooth codecs
– Sub Band Codec (SBC)
– Advanced Audio Coding (AAC)
Connect the microphone
BLUETOOTH® (for / )
Adjust the
microphone angle
Secure using cord clamps (not
supplied) if necessary.
Microphone
input jack
Microphone
(supplied)
Rear panel
Pair and connect a Bluetooth device for the first time
1
Press
to turn on the unit.
2 Search and select this unit model name (KMM-BT3* * /KMM -BT2* * ) on the Bluetooth
device.
“PAIRING”
“PASS XXXXXX” Device name “PRESS” “VOLUME KNOB” appears on
the display.
• For some Bluetooth devices, you may need to enter the Personal Identification
Number (PIN) code im mediately after searching.
3 Press the volume knob to start pairing.
“PAIRING OK” appears when pairing is complet ed.
Once pairing is completed, Bluet ooth connection is established automatically.
•
: “BT1” and/or “BT2” indicator on the faceplate lights up.
•
: “BT1” and/or “BT2” on the display window lights up.
• This unit supports Secure Simple Pairing (SSP).
• Up to five devices can be registered (paired) in total.
• Once t he pairing is completed, the Bluetooth device w ill remain registered in the unit
even if you reset the unit. To delete the paired device,
16, [DEVICE DELETE] .
• A maximum of two Bluetooth phones and one Bluet ooth audio device can be connected
at any time.
However, while in BT AUDIO source, you can connect to five Bluetooth audio devices and
switch between these five devices.
( 17)
• Som e Bluet ooth devices may not automatically connect to the unit after pairing. Connect
the device to the unit manually.
• Refer to the instruct ion manual of the Bluetoot h device for more information.
*
For the location of the microphone input jack, refer to page 29.

Kenwood KMM-BT304 Specifications

General

DIN size	1 DIN
Impedance	600 Ω
Clock mode	24h
Output power	20 W
Product color	Black
Ready for iPod	Yes
Volume control	Rotary
Frequency range	20 - 20000 Hz
Disc types supported	No
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Display type	LCD
Display digits	13 digits
Illumination color	-
Display number of lines	1.5 lines
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, RUS
USB version	2.0
Bluetooth range	10 m
Bluetooth version	3.0+HS
USB port position	Front
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP, SPP, SSP
USB ports quantity	1
Bluetooth functions	Audiostreaming, Handsfree calling
FM band range	0.00003 - 0.015 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	24
Hands-free calling	Keep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	600 g
