Kenwood KMM-BT304 User Manual

ENGLISH
3
BASICS
To On the faceplate
Turn on the power
Press
.
• Press and hold to turn off the power.
Adjust the volume Turn the volume knob.
Select a source
Press
repeatedly.
Change the display information Press DISP repeatedly.
( 31)
Faceplate
How to reset
Attach
De tach
Volume
knob
Detach
button
For
/ : Flashes
when the unit enters searching status.
For
:
Lights up when
Bluetooth
connection is
established.
( 12)
Reset the unit within 5 seconds
after detaching the faceplate.

Kenwood KMM-BT304 Specifications

General

DIN size	1 DIN
Impedance	600 Ω
Clock mode	24h
Output power	20 W
Product color	Black
Ready for iPod	Yes
Volume control	Rotary
Frequency range	20 - 20000 Hz
Disc types supported	No
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Display type	LCD
Display digits	13 digits
Illumination color	-
Display number of lines	1.5 lines
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, RUS
USB version	2.0
Bluetooth range	10 m
Bluetooth version	3.0+HS
USB port position	Front
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP, SPP, SSP
USB ports quantity	1
Bluetooth functions	Audiostreaming, Handsfree calling
FM band range	0.00003 - 0.015 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	24
Hands-free calling	Keep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	600 g
