Audio Performance| rated power output during stereo operation | 110 W + 110 W |
|---|---|
| effective power output during surround operation - front | 100 W + 100 W |
| effective power output during surround operation - center | 100 W |
| effective power output during surround operation - surround | 100 W + 100 W |
| total harmonic distortion | 0.050% (1 kHz, 50W, 6 Ω) |
| frequency response | 10 Hz ~ 60 kHz, +0 dB, –3.0 dB |
| signal to noise ratio - phono | 74 dB |
| signal to noise ratio - cd | 90 dB |
Input/Output Sensitivity and Impedance| input sensitivity / impedance - phono | 2.5 mV / 27 kΩ |
|---|---|
| input sensitivity / impedance - cd | 200 mV / 47 kΩ |
| input sensitivity / impedance - video2/monitor | 200 mV / 47 kΩ |
| input sensitivity / impedance - dvd/6ch input | 200 mV / 10 kΩ |
| output level / impedance - tape rec | 200 mV / 1 kΩ |
| output level / impedance - video2/monitor | 200 mV / 1 kΩ |
| output level / impedance - pre out (subwoofer) | 1.5 V / 2.2 kΩ |
Tone Control| bass | ±10 dB (at 70 Hz) |
|---|---|
| treble | ±10 dB (at 10 kHz) |
Dimensions and Weight| dimensions - width | 440 mm |
|---|---|
| dimensions - height | 143 mm |
| dimensions - depth | 400 mm |
| weight | 8.6 kg |
Audio Performance| rated power output during stereo operation | 110 W + 110 W |
|---|---|
| effective power output during surround operation - front | 100 W + 100 W |
| effective power output during surround operation - center | 100 W |
| effective power output during surround operation - surround | 100 W + 100 W |
| total harmonic distortion | 0.050% (1 kHz, 50W, 6 Ω) |
| frequency response | 40 Hz ~ 60 kHz, +0 dB, –3.0 dB |
| signal to noise ratio - phono | 74 dB |
| signal to noise ratio - cd | 90 dB |
Input/Output Sensitivity and Impedance| input sensitivity / impedance - phono | 2.5 mV / 27 kΩ |
|---|---|
| input sensitivity / impedance - cd | 200 mV / 47 kΩ |
| input sensitivity / impedance - monitor in (video2/monitor) | 200 mV / 47 kΩ |
| input sensitivity / impedance - dvd/6ch input | 200 mV / 47 kΩ |
| output level / impedance - tape rec | 200 mV / 1 kΩ |
| output level / impedance - monitor out (video2/monitor) | 200 mV / 1 kΩ |
| output level / impedance - pre out (subwoofer) | 1.5 V / 2.2 kΩ |
Tone Control| bass | ±10 dB (at 70 Hz) |
|---|---|
| treble | ±10 dB (at 10 kHz) |
Dimensions and Weight| dimensions - width | 440 mm |
|---|---|
| dimensions - height | 143 mm |
| dimensions - depth | 400 mm |
| weight | 8.5 kg |
Power and Consumption| power consumption | 250 W |
|---|---|
| ac outlet switched | total 90 W max. |
Procedure to reset the microcomputer if it malfunctions, restoring normal operation.
Details the default settings for various functions upon microcomputer initialization.
Explains how the receiver retains its last state when power is cycled.
Illustrates the block diagram of the microprocessor and its connected peripheral components.
Provides a detailed list of microprocessor pins, their I/O, and functions.
Details the interface between the AK4112AVF and the micro-computer.
Details the interface between the AK4527B and the micro-computer.
Explains how to enter, cancel, and the contents of the test mode.
Technical specifications for the audio section of the KRF-V6050D model.
Specifications for digital audio inputs and sampling frequency.
Specifications for video inputs, outputs, and S-Video signals.
Technical specifications for the FM tuner, including frequency range and sensitivity.
Technical specifications for the audio section of the KRF-V6050D model for other countries.
Technical specifications for the audio section of the KRF-V5050D model.
Technical specifications for the audio section of the KRF-V5550D model.
Technical specifications for the audio section of the KRF-V7050D model.
Technical specifications for the FM tuner in Europe.
Technical specifications for the MW tuner in Europe.
Technical specifications for the FM tuner for other countries.
