Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R51 ,52 RS14KB3D220J FL-PROOF RS 22 J 2W
R141,142 RD14NB2E4R7J RD 4.7 J 1/4W
D51 ,52 HZS5.6N(B2) ZENER DIODE
D51 ,52 MTZJ5.6 ZENER DIODE
D51 ,52 MTZJ5.6(B) ZENER DIODE
D51 ,52 RD5.6ES(B) ZENER DIODE
D51 ,52 RD5.6ES(B2) ZENER DIODE
D101-103 HSS104 DIODE
D101-103 HSS104A DIODE
D101-103 1SS133 DIODE
IC1 ,2 NJM2279D ANALOGUE IC
IC3 NJU4052BD IC(4CH MPX/DE-MPX)
IC3 TC74HC4052AP IC(ANALOG MULTIPLEXER)
IC11-13 NJM2279D ANALOGUE IC
Q51 2SD2525 TRANSISTOR
Q52 2SB1640 TRANSISTOR
Q101 DTC124ESA DIGITAL TRANSISTOR
Q101 UN4212 DIGITAL TRANSISTOR
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
§
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
IC401,402 NJM2279M ANALOGUE IC 67
IC403 TC74HC4052AF MOS-IC 7
Q1 KTC3199(Y,GR) TRANSISTOR
Q1 2SC1740S(Q,R) TRANSISTOR
Q100-105 2SC2878(B) TRANSISTOR 9
Q200,201 KTC3199(Y,GR) TRANSISTOR 9
Q200,201 2SC1740S(Q,R) TRANSISTOR 9
Q202 KTA1273 TRANSISTOR
Q202 2SA1534A(R,S) TRANSISTOR
Q203 2SC3940A(R,S) TRANSISTOR
Q203 2SD1768S TRANSISTOR
Q204 KTC3199(Y,GR) TRANSISTOR
Q204 2SC1740S(Q,R) TRANSISTOR
Q205 KTA1267(Y,GR) TRANSISTOR
Q205 2SA933AS(Q,R) TRANSISTOR
Q401 DTC124ESA DIGITAL TRANSISTOR 6
Q401 UN4212 DIGITAL TRANSISTOR 6
A2 W02-2625-05 OPTIC RECEIVING MODULE
C1 -12 CC45FSL1H470J CERAMIC 47PF J
C13 -17 CK45FF1H103Z CERAMIC 0.010UF Z
C18 -21 CE04PW1C470M ELECTRO 47UF 16WV
C22 CE04PW1E470M ELECTRO 47UF 25WV
C31 CK45FF1H103Z CERAMIC 0.010UF Z
C32 ,33 CE04LW1V100M ELECTRO 10UF 35WV
C53 ,54 CE04LW1V100M ELECTRO 10UF 35WV
C101 CC45FSL1H470J CERAMIC 47PF J
C102 CE04PW1E470M ELECTRO 47UF 25WV
C103 CC45FSL1H470J CERAMIC 47PF J
C104 CE04PW1E470M ELECTRO 47UF 25WV
C105 CC45FSL1H470J CERAMIC 47PF J
C106 CE04PW1E470M ELECTRO 47UF 25WV
C107 CC45FSL1H470J CERAMIC 47PF J
C108 CE04PW1E470M ELECTRO 47UF 25WV
C109 CC45FSL1H470J CERAMIC 47PF J
C110 CE04PW1E470M ELECTRO 47UF 25WV
C111 CC45FSL1H470J CERAMIC 47PF J
C112 CE04PW1E470M ELECTRO 47UF 25WV
C121-123 CC45FSL1H470J CERAMIC 47PF J
C131-133 CK45FF1H103Z CERAMIC 0.010UF Z
C141,142 CE04LW1V100M ELECTRO 10UF 35WV
C143 CK45FF1H103Z CERAMIC 0.010UF Z
CN1 E40-8483-05 FLAT CABLE CONNECTOR
J1 ,2 E56-0011-05 CYLINDRICAL RECEPTACLE
J11 ✽ E63-1193-05 PIN JACK
J11 ✽ E63-1195-05 PIN JACK
J11 ✽ E63-1197-05 PIN JACK
J12 ✽ E63-1194-05 PIN JACK
J12 ✽ E63-1196-05 PIN JACK
J12 ✽ E63-1198-05 PIN JACK
E1 J11-0809-05 WIRE CLAMPER
R31 ,32 RD14NB2E4R7J RD 4.7 J 1/4W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
∞
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
KRF-V5050D/V5550D/V6050D/V7050D/X9050D
47
PARTS LIST
VIDEO UNIT (X35-2252-71)
HOW TO READ THE PARTS LIST
ABBREVIATION OF MODEL AND MASS PRODUCTION'S DESTINATIONS
MODEL
Australia Canada China England Europe Germany Korea Malaysia
ABB.
KRF-V5050D
---T E---
KRF-V5050DE
----E3---
KRF-V5050D-S
X--T2E2- - I
KRF-V5550D-S
---- ----
KRF-V6050D
---- E---
KRF-V6050D-S
X--- -- - I
KRF-V7050D
---T E---
KRF-V7050D-S
X--- -- - I
KRF-X9050D
---T E---
KRF-X9050D-S
X--- -- - I
MODEL
Mexico PX/AAFES Russia Scandinavia Shanghai USA Other area
ABB.
KRF-V5050D
-Y-- -- - -
KRF-V5050DE
---- ----
KRF-V5050D-S
---- --M-
KRF-V5550D-S
-Y-- --M-
KRF-V6050D
-Y-- -- - -
KRF-V6050D-S
---- --M-
KRF-V7050D
-Y-- -- - -
KRF-V7050D-S
---- --M-
KRF-X9050D
-Y-- -- - -
KRF-X9050D-S
---- --M-
