Kenwood KRF-V5050D Service Manual

Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
- ✽ H50-3998-04 ITEM CARTON CASE YT
- ✽ H50-3999-04 ITEM CARTON CASE X
- ✽ H50-4000-04 ITEM CARTON CASE MI
- ✽ H50-4001-04 ITEM CARTON CASE E
- ✽ H50-4002-04 ITEM CARTON CASE E2
- ✽ H50-4003-04 ITEM CARTON CASE E3
- ✽ H50-4004-04 ITEM CARTON CASE T2
641 2B,2C J02-1464-03 FOOT
642 2B,2C J19-3751-04 UNIT HOLDER
643 1C J19-6078-05 UNIT HOLDER
647 1C J42-0083-05 POWER CORD BUSHING
- J61-0307-05 WIRE BAND
650 2B K29-7675-22 KNOB CENTER KEY YETE2
650 2B K29-7676-22 KNOB CENTER KEY E3T2
650 2B K29-7676-22 KNOB CENTER KEY MXI
651 2B K29-7678-04 KNOB VOLUME CONTROL YETE2
651 2B K29-7679-04 KNOB VOLUME CONTROL E3T2
651 2B K29-7679-04 KNOB VOLUME CONTROL MXI
652 2A K29-7681-14 KNOB INPUT SELECTOR YETE2
652 2A K29-7682-14 KNOB INPUT SELECTOR E3T2
652 2A K29-7682-14 KNOB INPUT SELECTOR MXI
653 2A K29-7684-03 KNOB MULTI CONTROL YETE2
653 2A K29-7685-03 KNOB MULTI CONTROL E3T2
653 2A K29-7685-03 KNOB MULTI CONTROL MXI
654 2B K29-7687-03 KNOB POWER ON/STANDBY YETE2
654 2B K29-7688-03 KNOB POWER ON/STANDBY E3T2
654 2B K29-7688-03 KNOB POWER ON/STANDBY MXI
655 2A K27-2384-04 KNOB (BUTTON) POWER ON/OFF YETE2
655 2A K27-2385-04 KNOB (BUTTON) POWER ON/OFF E3T2
655 2A K27-2385-04 KNOB (BUTTON) POWER ON/OFF MXI
658 1B ✽ L07-2923-05 POWER TRANSFORMER YMI
658 1B ✽ L07-2924-05 POWER TRANSFORMER X
658 1B ✽ L07-2925-05 POWER TRANSFORMER ETE2
658 1B ✽ L07-2925-05 POWER TRANSFORMER E3T2
661 1A T90-0852-05 LOOP ANTENNA
662 1A ✽ T90-0877-05 LEAD WIRE ANTENNA
665 2C ✽ W02-2772-05 TUNER ASSY YMXI
665 2C ✽ W02-2773-05 TUNER ASSY ETE2
665 2C ✽ W02-2773-05 TUNER ASSY E3T2
665 2C ✽ W02-2776-05 TUNER ASSY YMXI
665 2C ✽ W02-2777-05 TUNER ASSY ETE2
665 2C ✽ W02-2777-05 TUNER ASSY E3T2
601 1A ✽ A01-3795-01 METALLIC CABINET YE
601 1A ✽ A01-3796-01 METALLIC CABINET MXI
602 1A A09-1178-08 BATTERY COVER
605 2B ✽ A60-1929-01 PANEL YE
605 2B ✽ A60-1930-01 PANEL MXI
606 1A ✽ A70-1466-15 REMOTE CONTROL ASSY RC-R0615 YMXI
606 1A ✽ A70-1467-05 REMOTE CONTROL ASSY RC-R0616 E
610 2A ✽ B07-2550-02 ESCUTCHEON YE
610 2A ✽ B07-2551-02 ESCUTCHEON MXI
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
601 1A ✽ A01-3795-01 METALLIC CABINET YETE2
601 1A ✽ A01-3796-01 METALLIC CABINET E3T2
601 1A ✽ A01-3796-01 METALLIC CABINET MXI
602 1A A09-1178-08 BATTERY COVER
605 2B ✽ A60-1933-01 PANEL E3T2
605 2B ✽ A60-1933-01 PANEL MXI
605 2B ✽ A60-1934-01 PANEL YETE2
606 1A ✽ A70-1468-15 REMOTE CONTROL ASSY RC-R0511 YMXI
606 1A ✽ A70-1469-05 REMOTE CONTROL ASSY RC-R0512 ETE2
606 1A ✽ A70-1469-05 REMOTE CONTROL ASSY RC-R0512 E3T2
610 2A ✽ B07-2550-02 ESCUTCHEON YETE2
610 2A ✽ B07-2551-02 ESCUTCHEON E3T2
610 2A ✽ B07-2551-02 ESCUTCHEON MXI
611 2A ✽ B10-3658-02 FRONT GLASS YMXI
611 2A ✽ B10-3670-02 FRONT GLASS ETE2
611 2A ✽ B10-3670-02 FRONT GLASS E3T2
613 2B B12-0384-04 INDICATOR
614 2B B12-0385-04 INDICATOR
615 2A B43-0314-04 KENWOOD BADGE
- B46-0096-53 WARRANTY CARD X
- B46-0310-03 WARRANTY CARD ETE2
- B46-0310-03 WARRANTY CARD E3T2
- B46-0328-03 WARRANTY CARD Y
- B58-0513-04 CAUTION CARD (PRESET220-240) Y
- B58-0945-03 CAUTION CARD TT2
- B58-0964-13 CAUTION CARD (UL) Y
- B58-0965-13 CAUTION CARD (T,XtypePL) XTT2
- B58-0966-13 CAUTION CARD (ELMtypePL) MIEE3
- B58-1607-03 CAUTION CARD E2
- B59-1104-00 SERVICE DIRECTORY Y
- ✽ B60-4942-00 INSTRUCTION MANUAL (EN) YMXI
- ✽ B60-4944-00 INSTRUCTION MANUAL (ES) M
- ✽ B60-4945-00 INSTRUCTION MANUAL (TC) MI
- ✽ B60-4947-00 INSTRUCTION MANUAL (EN) TE2T2
- ✽ B60-4948-00 INSTRUCTION MANUAL (FR/GE) EE3
- ✽ B60-4949-00 INSTRUCTION MANUAL (NE/IT) EE3
- ✽ B60-4950-00 INSTRUCTION MANUAL (ES) EE3
- ✽ B60-4951-00 INSTRUCTION MANUAL (PL/RU) E2
- ✽ B60-4952-00 INSTRUCTION MANUAL (CZ/HU) E2
619 1A E03-0115-05 AC PLUG ADAPTER M
620 1C E30-2605-05 AC POWER CORD Y
620 1C E30-2717-05 AC POWER CORD X
620 1C E30-2721-05 AC POWER CORD TT2
620 1C E30-2942-05 AC POWER CORD E2E3
620 1C E30-2942-05 AC POWER CORD MIE
621 2B,2C ✽ E35-2774-15 FLAT CABLE 21P
623 1C,2C ✽ E35-2776-05 FLAT CABLE 29P
624 1C ✽ E35-2777-05 FLAT CABLE 23P
625 1C,2C ✽ E35-2841-05 FLAT CABLE 19P
- ✽ H10-7743-02 POLYSTYRENE FOAMED FIXTURE
- ✽ H10-7744-02 POLYSTYRENE FOAMED FIXTURE
- H25-0232-04 PROTECTION BAG (235X350X0.03)
- H25-0391-04 PROTECTION BAG
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
KRF-V5050D/V5550D/V6050D/V7050D/X9050D
35
PARTS LIST
KRF-V5050D/V5050DE/V5050D-S
KRF-V6050D/V6050D-S
