Kenwood KRF-V5050D Service Manual

Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
620 1C E30-2605-05 AC POWER CORD Y
620 1C E30-2942-05 AC POWER CORD M
621 2B,2C ✽ E35-2774-15 FLAT CABLE 21P
623 1C,2C ✽ E35-2776-05 FLAT CABLE 29P
624 1C ✽ E35-2777-05 FLAT CABLE 23P
625 1C,2C ✽ E35-2841-05 FLAT CABLE 19P
- ✽ H10-7743-02 POLYSTYRENE FOAMED FIXTURE
- ✽ H10-7744-02 POLYSTYRENE FOAMED FIXTURE
- H25-0232-04 PROTECTION BAG (235X350X0.03)
- H25-0391-04 PROTECTION BAG
- ✽ H50-4043-04 ITEM CARTON CASE M
- ✽ H50-4148-04 ITEM CARTON CASE Y
641 2B,2C J02-1464-03 FOOT
642 2B,2C J19-3751-04 UNIT HOLDER
643 1C J19-6078-05 UNIT HOLDER
647 1C J42-0083-05 POWER CORD BUSHING
- J61-0307-05 WIRE BAND
650 2B K29-7676-22 KNOB CENTER KEY
651 2B K29-7679-04 KNOB VOLUME CONTROL
652 2A K29-7682-14 KNOB INPUT SELECTOR
653 2A K29-7685-03 KNOB MULTI CONTROL
654 2B K29-7688-03 KNOB POWER ON/STANDBY
655 2A K27-2385-04 KNOB (BUTTON) POWER ON/OFF
658 1B ✽ L07-2926-05 POWER TRANSFORMER
661 1A T90-0852-05 LOOP ANTENNA
662 1A ✽ T90-0877-05 LEAD WIRE ANTENNA
665 1C ✽ W02-2772-05 TUNER ASSY
665 1C ✽ W02-2776-05 TUNER ASSY
601 1A ✽ A01-3793-01 METALLIC CABINET YET
601 1A ✽ A01-3794-01 METALLIC CABINET MXI
602 1A A09-1215-08 BATTERY COVER
604 2A ✽ A22-1851-01 SUB PANEL YET
604 2A ✽ A22-1852-01 SUB PANEL MXI
605 2B ✽ A60-1937-02 PANEL MXI
605 2B ✽ A60-1938-02 PANEL YET
606 1A ✽ A70-1480-05 REMOTE CONTROL ASSY RC-R0714 YMXI
606 1A ✽ A70-1481-05 REMOTE CONTROL ASSY RC-R0715 ET
611 2A ✽ B10-3645-12 FRONT GLASS YXI
611 2A ✽ B10-3646-12 FRONT GLASS M
611 2A ✽ B10-3647-12 FRONT GLASS ET
612 2A B12-0341-04 INDICATOR
613 2B B12-0383-04 INDICATOR
615 2A B43-0314-04 KENWOOD BADGE
- B46-0096-53 WARRANTY CARD X
- B46-0310-03 WARRANTY CARD ET
- B46-0328-03 WARRANTY CARD Y
- B58-0513-04 CAUTION CARD (PRESET220-240) Y
- B58-0945-03 CAUTION CARD T
- B58-0964-13 CAUTION CARD (UL) Y
- B58-0965-13 CAUTION CARD (T,XtypePL) XT
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
6
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
625 1C,2C ✽ E35-2841-05 FLAT CABLE 19P
- ✽ H10-7743-02 POLYSTYRENE FOAMED FIXTURE
- ✽ H10-7744-02 POLYSTYRENE FOAMED FIXTURE
- H25-0232-04 PROTECTION BAG (235X350X0.03)
- H25-0391-04 PROTECTION BAG
- ✽ H50-3987-04 ITEM CARTON CASE YT
- ✽ H50-3988-04 ITEM CARTON CASE X
- ✽ H50-3989-04 ITEM CARTON CASE MI
- ✽ H50-3991-04 ITEM CARTON CASE E
641 2B,2C J02-1464-03 FOOT
642 2B,2C J19-3751-04 UNIT HOLDER
643 1C J19-6078-05 UNIT HOLDER
647 1C J42-0083-05 POWER CORD BUSHING
- J61-0307-05 WIRE BAND
650 2B K29-7675-22 KNOB CENTER KEY YET
650 2B K29-7676-22 KNOB CENTER KEY MXI
651 2B K29-7678-04 KNOB VOLUME CONTROL YET
651 2B K29-7679-04 KNOB VOLUME CONTROL MXI
652 2A K29-7681-14 KNOB MULTI/INPUT YET
652 2A K29-7682-14 KNOB MULTI/INPUT MXI
654 2B K29-7687-03 KNOB POWER ON/STANDBY Y
654 2B K29-7688-03 KNOB POWER ON/STANDBY MXI
655 2A K27-2384-04 KNOB (BUTTON) POWER ON/OFF YET
655 2A K27-2385-04 KNOB (BUTTON) POWER ON/OFF MXI
658 1B ✽ L07-2923-05 POWER TRANSFORMER YMI
658 1B ✽ L07-2924-05 POWER TRANSFORMER X
658 1B ✽ L07-2925-05 POWER TRANSFORMER ET
661 1A T90-0852-05 LOOP ANTENNA
662 1A ✽ T90-0877-05 LEAD WIRE ANTENNA
665 2C ✽ W02-2772-05 TUNER ASSY YMXI
665 2C ✽ W02-2773-05 TUNER ASSY ET
665 2C ✽ W02-2776-05 TUNER ASSY YMXI
665 2C ✽ W02-2777-05 TUNER ASSY ET
601 1A ✽ A01-3796-01 METALLIC CABINET
602 1A A09-1178-08 BATTERY COVER
605 2B ✽ A60-1997-01 PANEL
606 2B ✽ A70-1507-05 REMOTE CONTROL ASSY RC-R0617
610 2A ✽ B07-2551-02 ESCUTCHEON
611 2A ✽ B10-3678-02 FRONT GLASS
613 2B B12-0384-04 INDICATOR
614 2B B12-0385-04 INDICATOR
615 2A B43-0314-04 KENWOOD BADGE
- B46-0328-03 WARRANTY CARD Y
- B58-0513-04 CAUTION CARD (PRESET220-240) Y
- B58-0964-13 CAUTION CARD (UL) Y
- B58-0966-13 CAUTION CARD (ELMtypePK) M
- B59-1104-00 SERVICE DIRECTORY Y
- ✽ B60-4942-00 INSTRUCTION MANUAL (EN)
- ✽ B60-4944-00 INSTRUCTION MANUAL (ES) M
- ✽ B60-4945-00 INSTRUCTION MANUAL (TC) M
619 1A E03-0115-05 AC PLUG ADAPTER M
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
5
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
KRF-V5050D/V5550D/V6050D/V7050D/X9050D
37
PARTS LIST
KRF-V5550D-S
KRF-X9050D/X9050D-S
