Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
KRF-V5050D/V5550D/V6050D/V7050D/X9050D
36
PARTS LIST
658 1B ✽ L07-2923-05 POWER TRANSFORMER YMI
658 1B ✽ L07-2924-05 POWER TRANSFORMER X
658 1B ✽ L07-2925-05 POWER TRANSFORMER E
661 1A T90-0852-05 LOOP ANTENNA
662 1A ✽ T90-0877-05 LEAD WIRE ANTENNA
665 2C ✽ W02-2772-05 TUNER ASSY YMXI
665 2C ✽ W02-2773-05 TUNER ASSY E
665 2C ✽ W02-2776-05 TUNER ASSY YMXI
665 2C ✽ W02-2777-05 TUNER ASSY E
601 1A ✽ A01-3793-01 METALLIC CABINET ET
601 1A ✽ A01-3795-01 METALLIC CABINET Y
601 1A ✽ A01-3796-01 METALLIC CABINET MXI
602 1A A09-1178-08 BATTERY COVER
604 2A ✽ A22-1853-01 SUB PANEL ET
605 2A ✽ A60-1744-12 PANEL ET
605 2A ✽ A60-1929-01 PANEL Y
605 2A ✽ A60-1930-01 PANEL MXI
606 1A ✽ A70-1464-15 REMOTE CONTROL ASSY RC-R0613 YMXI
606 1A ✽ A70-1465-05 REMOTE CONTROL ASSY RC-R0614 ET
610 2A ✽ B07-2554-02 ESCUTCHEON Y
610 2A ✽ B07-2555-02 ESCUTCHEON MXI
611 2A ✽ B10-3650-12 FRONT GLASS YXI
611 2A ✽ B10-3651-12 FRONT GLASS M
611 2A ✽ B10-3652-12 FRONT GLASS ET
612 2A B12-0341-04 INDICATOR ET
613 2B B12-0383-04 INDICATOR
614 2B B12-0385-04 INDICATOR YMXI
615 2A B43-0314-04 KENWOOD BADGE
- B46-0096-53 WARRANTY CARD X
- B46-0310-03 WARRANTY CARD ET
- B46-0328-03 WARRANTY CARD Y
- B58-0513-04 CAUTION CARD (PRESET220-240) Y
- B58-0945-03 CAUTION CARD T
- B58-0964-13 CAUTION CARD (UL) Y
- B58-0965-13 CAUTION CARD (T,XtypePL) XT
- B58-0966-13 CAUTION CARD (ELMtypePL) MIE
- B59-1104-00 SERVICE DIRECTORY Y
- ✽ B60-4942-00 INSTRUCTION MANUAL (EN) YMXI
- ✽ B60-4944-00 INSTRUCTION MANUAL (ES) M
- ✽ B60-4945-00 INSTRUCTION MANUAL (TC) MI
- ✽ B60-4947-00 INSTRUCTION MANUAL (EN) T
- ✽ B60-4948-00 INSTRUCTION MANUAL (FR/GE) E
- ✽ B60-4949-00 INSTRUCTION MANUAL (NE/IT) E
- ✽ B60-4950-00 INSTRUCTION MANUAL (ES) E
619 1A E03-0115-05 AC PLUG ADAPTER M
620 1C E30-2605-05 AC POWER CORD Y
620 1C E30-2717-05 AC POWER CORD X
620 1C E30-2721-05 AC POWER CORD T
620 1C E30-2942-05 AC POWER CORD MIE
621 2B,2C ✽ E35-2774-15 FLAT CABLE 21P
622 2B,2C ✽ E35-2775-15 FLAT CABLE 7P
623 1C,2C ✽ E35-2776-05 FLAT CABLE 29P
624 1C ✽ E35-2777-05 FLAT CABLE 23P
4
611 2A ✽ B10-3655-02 FRONT GLASS YMXI
611 2A ✽ B10-3656-02 FRONT GLASS E
613 2B B12-0384-04 INDICATOR
614 2B B12-0385-04 INDICATOR
615 2A B43-0314-04 KENWOOD BADGE
- B46-0096-53 WARRANTY CARD X
- B46-0310-03 WARRANTY CARD E
- B46-0328-03 WARRANTY CARD Y
- B58-0513-04 CAUTION CARD (PRESET220-240) Y
- B58-0964-13 CAUTION CARD (UL) Y
- B58-0965-13 CAUTION CARD (T,XtypePL) X
- B58-0966-13 CAUTION CARD (ELMtypePL) MIE
- B59-1104-00 SERVICE DIRECTORY Y
- ✽ B60-4942-00 INSTRUCTION MANUAL (EN) YMXI
- ✽ B60-4944-00 INSTRUCTION MANUAL (ES) M
- ✽ B60-4945-00 INSTRUCTION MANUAL (TC) MI
- ✽ B60-4948-00 INSTRUCTION MANUAL (FR/GE) E
- ✽ B60-4949-00 INSTRUCTION MANUAL (NE/IT) E
- ✽ B60-4950-00 INSTRUCTION MANUAL (ES) E
619 1A E03-0115-05 AC PLUG ADAPTER M
620 1C E30-2605-05 AC POWER CORD Y
620 1C E30-2717-05 AC POWER CORD X
620 1C E30-2942-05 AC POWER CORD MIE
621 2B,2C ✽ E35-2774-15 FLAT CABLE 21P
622 2B,2C ✽ E35-2775-15 FLAT CABLE 7P
623 1C,2C ✽ E35-2776-05 FLAT CABLE 29P
624 1C ✽ E35-2777-05 FLAT CABLE 23P
625 1C,2C ✽ E35-2841-05 FLAT CABLE 19P
- ✽ H10-7743-02 POLYSTYRENE FOAMED FIXTURE
- ✽ H10-7744-02 POLYSTYRENE FOAMED FIXTURE
- H25-0232-04 PROTECTION BAG (235X350X0.03)
- H25-0391-04 PROTECTION BAG
- ✽ H50-3993-04 ITEM CARTON CASE Y
- ✽ H50-3994-04 ITEM CARTON CASE X
- ✽ H50-3995-04 ITEM CARTON CASE MI
- ✽ H50-3996-04 ITEM CARTON CASE E
641 2B,2C J02-1464-03 FOOT
642 2B,2C J19-3751-04 UNIT HOLDER
643 1C J19-6078-05 UNIT HOLDER
647 1C J42-0083-05 POWER CORD BUSHING
- J61-0307-05 WIRE BAND
650 2B K29-7675-22 KNOB CENTER KEY YE
650 2B K29-7676-22 KNOB CENTER KEY MXI
651 2B K29-7678-04 KNOB VOLUME CONTROL YE
651 2B K29-7679-04 KNOB VOLUME CONTROL MXI
652 2A K29-7681-14 KNOB INPUT SELECTOR YE
652 2A K29-7682-14 KNOB INPUT SELECTOR MXI
653 2A K29-7684-03 KNOB MULTI CONTROL YE
653 2A K29-7685-03 KNOB MULTI CONTROL MXI
654 2B K29-7687-03 KNOB POWER ON/STANDBY YE
654 2B K29-7688-03 KNOB POWER ON/STANDBY MXI
655 2A K27-2384-04 KNOB (BUTTON) POWER ON/OFF YE
655 2A K27-2385-04 KNOB (BUTTON) POWER ON/OFF MXI
3
KRF-V7050D/V7050D-S
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
