TK-8102
23
PARTS LIST
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Europe
Y : AAFES (Europe) X : Australia M :Other Areas
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description
Desti-
nation
New
parts
TK-8102
DISPLAY UNIT (X54-3460-20)
TX-RX UNIT (X57-6920-XX)
11BA01-2178-02 CABINET
23B✽ A10-4080-01 CHASSIS
33AA62-0942-03 PANEL ASSY
53A✽ B10-2753-03 FRONT GLASS
72CB62-1389-10 INSTRUCTION MANUAL
83B✽ B72-1946-24 MODEL NAME PLATE M
83B✽ B72-1947-14 MODEL NAME PLATE M2
83B✽ B72-1948-14 MODEL NAME PLATE M3
10 3B E04-0167-05 RF COAXIAL PECEPTACLE (M)
12 1C E30-3339-05 DC CORD ACCESSORY
13 2B E30-3448-05 DC CORD (RADIO)
14 3A E37-0962-05 SPEAKER CABLE
15 2A E37-1041-05 FLAT CABLE (TX/RX-DISPLAY)
20 2B F10-2414-03 SHIELDING PLATE (POWER MODULE)
21 2B ✽ F10-2491-02 SHIELDING COVER (TX/RX)
22 2B ✽ F10-2498-03 SHIELDING CASE (POWER MODULE)
23 1C F51-0016-05 FUSE (6✽30) ACCESSORY
25 2B G02-0887-03
EARTH SPRING (ANTENNA TERMINAL)
26 2B G10-0792-14 FIBROUS SHEET (POWER MODULE)
27 3A G13-1836-04 CUSHION (SPEAKER)
30 3B ✽ G13-2003-04 CUSHION (DC CORD)
34 1B G53-1524-02 PACKING (CABINET)
35 3B G53-1525-03 PACKING (PANEL)
36 2B G53-1542-03 PACKING (PHONE JACK)
38 1C H02-0617-02 INNER PACKING CASE
39 2D H10-6636-13 POLYSTYRENE FOAMED FIXTURE
40 3C H10-6639-03 POLYSTYRENE FOAMED FIXTURE
41 1C H25-0103-04 PROTECTION BAG (125/250/0.07)
42 2D H25-2320-04 PROTECTION BAG
43 3D H52-1699-12 ITEM CARTON CASE
46 1D J29-0662-03 BRACKET ACCESSORY
48 2A K29-9065-01 KEY TOP
A2BN67-3008-46 PAN HEAD SEMS SCREW W
B 2B,3B N87-2606-46 BRAZIER HEAD TAPTITE SCREW
C 1B,2B N87-2614-46 BRAZIER HEAD TAPTITE SCREW
50 1C N99-0395-05 SCREW SET ACCESSORY
52 3A T07-0739-05 SPEAKER
D1-4 B30-2238-05 LED (Y)
D5-10 B30-2239-05 LED (SY)
D11 B30-2237-05 LED (YG)
D12 B30-2240-05 LED (SR)
C4 CK73GB1H103K CHIP C 0.010UF K
C8-17 CK73GB1H103K CHIP C 0.010UF K
C18 CK73GB1A105K CHIP C 1.0UF K
C25 CK73GB1H103K CHIP C 0.010UF K
C27 CK73GB1C104K CHIP C 0.10UF K
CN1 E40-6005-05 FLAT CABLE CONNECTOR
J1 E08-0877-05 MODULAR JACK
L1 L92-0138-05 FERRITE CHIP
CP3,4 RK75GB1J392J CHIP-COM 3.9K J 1/16W
R1-6 RK73GB1J102J CHIP R 1.0K J 1/16W
R7-15 RK73FB2A272J CHIP R 2.7K J 1/10W
R16 RK73GB1J101J CHIP R 100 J 1/16W
R17 RK73GB1J100J CHIP R 10 J 1/16W
R18 RK73GB1J472J CHIP R 4.7K J 1/16W
R19,20 RK73GB1J222J CHIP R 2.2K J 1/16W
D13 DA221 DIODE
IC1 BU2090FS MOS IC
Q4 KRC102S DIGITAL TRANSISTOR
Q9 KRA225S DIGITAL TRANSISTOR
Q10 KRC102S DIGITAL TRANSISTOR
C10 CK73GB1H102K CHIP C 1000PF K
C13-23 CK73GB1H471K CHIP C 470PF K
C26-28 CK73GB1H221K CHIP C 220PF K
C29 CK73GB1H471K CHIP C 470PF K
C30 CK73GB1H102K CHIP C 1000PF K
C32 CK73GB1H102K CHIP C 1000PF K
C33 CK73GB1H471K CHIP C 470PF K
C34 C92-0721-05 ELECTRO 330UF 25WV
C35-38 CK73GB1H471K CHIP C 470PF K
C39,40 CK73GB1C104K CHIP C 0.10UF K
C41 C92-0795-05 CHIP-TAN 22UF 10WV
C42 CK73GB1H103K CHIP C 0.010UF K
C43-45 C92-0795-05 CHIP-TAN 22UF 10WV
C48 CK73GB1C473K CHIP C 0.047UF K M
C48-50 CK73GB1H103K CHIP C 0.010UF K M2,M3
C49,50 CK73GB1H103K CHIP C 0.010UF K M
C51 C92-0560-05 CHIP-TAN 10UF 6.3WV
C52,53 CK73GB1H471K CHIP C 470PF K
C54,55 CK73GB1C104K CHIP C 0.10UF K
C56 CK73GB1H471K CHIP C 470PF K
C61 CK73GB1H471K CHIP C 470PF K
C66 CK73GB1H471K CHIP C 470PF K
C72 CK73GB1H471K CHIP C 470PF K
C77 CK73GB1H471K CHIP C 470PF K
C78 CK73GB1H102K CHIP C 1000PF K
C82 CK73GB1H471K CHIP C 470PF K
C83 CK73GB1C104K CHIP C 0.10UF K
C87 CC73GCH1H180J CHIP C 18PF J
C88,89 CC73GCH1H060B CHIP C 6.0PF B
C90 CC73GCH1H180J CHIP C 18PF J
C97,98 CK73GB1H471K CHIP C 470PF K
C101 CK73GB1H471K CHIP C 470PF K
C102 CK73GB1C104K CHIP C 0.10UF K
C103 CK73GB1H102K CHIP C 1000PF K
C104 CK73GB1C104K CHIP C 0.10UF K
TK-8102
DISPLAY UNIT (X54-3460-20)
TX-RX UNIT (X57-6920-XX) -22 : M -23 : M2 -24 : M3
