Key Automation TURBO SC122 User Manual

12
EN
2 - PRODUCT OVERVIEW
2.1 - Product description
2.2 - Model and technical characteristics
Irreversible electromechanical gearmotor for sliding gates operating at 24 Vdc and 230 Vac. (Fig.1)
CODE DESCRIPTION
SC50 230 Vac gear motor with mechanical limit switches, gate maximum weight 500 kg, without control unit
SC52 230 Vac gear motor with mechanical limit switches, gate maximum weight 500 kg
SC52M 230 Vac gear motor with magnetic limit switches, gate maximum weight 500 kg
SC4224 24 Vdc gear motor with mechanical limit switches, gate maximum weight 400 kg
SC80 230 Vac gear motor with mechanical limit switches, gate maximum weight 800 kg, without control unit
SC82 230 Vac gear motor with mechanical limit switches, gate maximum weight 800 kg
SC82M 230 Vac gear motor with magnetic limit switches, gate maximum weight 800 kg
TU7224 24 Vdc gear motor with mechanical limit switches, gate maximum weight 700 kg
SC120 230 Vac gear motor with mechanical limit switches, gate maximum weight 1200 kg, without control unit
SC122 230 Vac gear motor with mechanical limit switches, gate maximum weight 1200 kg
SC122M 230 Vac gear motor with magnetic limit switches, gate maximum weight 1200 kg
TU11224 24 Vdc gear motor with mechanical limit switches, gate maximum weight 1100 kg
SC162 230 Vac gear motor with mechanical limit switches, gate maximum weight 1600 kg
TECHNICAL DATA
MODEL SC50 SC52 SC52M SC4224
Speed* cm/s 16 16 16 21
Torque Nm 16 16 16 12
Working cycle % 30 30 30 50
Control unit - CT102B CT102B CT10224
Power Vac (Vdc) 230 230 230 230 (24)
Motor consumption A 1,3 1,3 1,3 1,1
Consumption power W 300 300 300 250
Capacitor
µF 12,5 12,5 12,5 -
Thermoprotection
°C 150 150 150 -
Protection degree IP 44 44 44 44
Dimension (L - P- H) mm 320 - 184 - 260 320 - 184 - 260 320 - 184 - 260 320 - 184 - 260
Weight Kg 12 12 12 11
Working temperature °C -20 +55 -20 +55 -20 +55 -20 +55
Max gate weight Kg 500 500 500 400
Sound emission level dB(A) ≤ 70 ≤ 70 ≤ 70 ≤ 70
TECHNICAL DATA
MODEL SC80 SC82 SC82M TU7224
Speed* cm/s 16 16 16 25
Torque Nm 29 29 29 26
Working cycle % 30 30 30 80
Control unit - CT102B CT102B CT10224
Power Vac (Vdc) 230 230 230 230 (24)
Motor consumption A 1,9 1,9 1,9 1,5
Consumption power W 450 450 450 345
Capacitor µF 16 16 16 -
Thermoprotection °C 150 150 150 -
Protection degree IP 44 44 44 44
Dimension (L - P- H) mm 320 - 184 - 260 320 - 184 - 260 320 - 184 - 260 320 - 184 - 260
Weight Kg 12,5 12,5 12,5 11
Working temperature °C -20 +55 -20 +55 -20 +55 -20 +55
Max gate weight Kg 800 800 800 700
Sound emission level dB(A) ≤ 70 ≤ 70 ≤ 70 ≤ 70
