Kipor KDE75SS3 User Manual

46
10.2 Technical specifications
(1) Single-phase
Model KDE11SS KDE16SS
Rated frequency Hz 50 60 50 60
KVA 8.5 10.5 13 15.5
Rated output
KW 8.5 10.5 13 15.5
Rated voltage V 115/230 120/240 115/230 120/240
Rated current A 74/37 87.6/43.8 113/56.5 129.2/64.6
Rated rotation speed r/minn 1500 1800 1500 1800
Phase no./ Excitation mode
Single phase /
Brushless self-excitation and constant voltage (with AVR)
Power factor (cosφ) 1.0
Insulation grade F
Generator
Pole number 4
Model KD388G KD488G
Type
Three cylinder, 4-stroke,
direct injection
Four cylinder, 4-stroke, direct
injection
Cylinder No.-Bore × Stroke mm 3－88×90 4－88×90
Displacement L 1.642 2.19
Compression ratio 18.2 1∶
Rated power KW（r/min） 12.3/1500 14.8/1800 16.4/1500 19.6/1800
Fuel type 0# (summer), -10# (winter), -35# (cold) light diesel
Lube oil type
Above CD grade, SAE 10W30 or 15W40
Fuel consumption g/kw.h
≤340 ≤320
Fuel tank capacity L 65 65
Engine
Continuous running time h 18 14 12 9
Overall dimension LXWXH mm 1570×780×1050
Net weight kg 685 720
Starting mode 12V electric starting
Noise at zero load dB(A)/1m 68 70 68 70
Noise at rated load dB（A）/7m 51 53 51 53
Set
Structure type Ultra silent
