22
ASSEMBLY INSTRUCTIONS
kobalttools.com
ASSEMBLY INSTRUCTIONS
BLADE INSTALLATION
CAUTION
To work properly, saw blade teeth must point down toward the front of the saw. Failure to do so
could cause damage to the saw blade, the saw, or the workpiece.
1. Make sure blade is turned right way. Remove blade
wrenches from storage area. Install blade and
washer (with small side facing outward), then apply
nut to shaft. Place open end wrench (G) on ats of
arbor shaft. Insert closed end wrench (F) over
blade nut.
To tighten the blade:
2. Holding both wrenches rmly, push closed end
wrench (F) to back of machine. Make sure blade
nut is securely tightened. DO NOT over tighten.
Reinstall the throat plate (Y). Check all clearances
for free blade rotation.
