29
kobalttools.com
BEFORE OPERATING
MITER GAUGE
The miter gauge provides accuracy in angled cuts. For very close tolerances, test cuts are
recommended.
There are two miter gauge grooves, one on either side of blade, maximum 30° on both left or right
side. . When making a 90° cross cut, use either miter gauge groove. When making a beveled cross
cut (blade tilted in relation to table (V), miter gauge should be located in groove on right so that blade
is tilted away from miter gauge and hands.
Using Miter Gauge
1. Loosen lock knob. With miter gauge in miter gauge
groove, rotate gauge until desired angle on scale is
reached. To lock retighten lock knob.
