TP-6811 7/1644 Section 3 Controller
16. Set up the controller as instructed in Section 3.6,
Controller Setup.
17. Calibrate the voltage. See Section 3.7, Voltage
Calibration.
18. If OnCuer Plus is used to monitor this generator
set, reset the OnCue password on the controller
and note the new password. See Section 3.8,
Setting the OnCuer Plus Password. Then connect
with OnCuer Plus and enter the new password.
19. Verify that OnCuer Plus can communicate with the
generator set over the Internet before leaving the
job site.
3.6 Controller Setup
Controller setup is required after installation. Follow the
instructions in this section to set the necessary
parameters.
Controller Setup Notes:
D Some of the required information can be found on the
generator set nameplate. See Figure 3-6 for the
nameplate location.
D The Engine Model Number is automatically selected
when the Genset Model Number is selected and the
change is applied.
D The Fuel Type parameter is available with controller
firmware versions 4.5 or higher. The fuel type setting
affects the generator set power rating, which is used
to determine setpoints for the optional load
management device. Setting the Fuel Type is
recommended if the generator set is connected to a
load management device.
Controller Setup Procedure
1. Use one of the methods listed below to set the
parameters shown in Figure 3-9.
a. Use the buttons on the controller to navigate
through the controller menus and change the
settings. See the required controller menus in
Figure 3-10 and Figure 3-11. See the
generator set operation manual for additional
instructions, if necessary.
b. Use a personal computer and Kohlerr
SiteTecht software to change the settings.
See Figure 3-12. Refer to TP-6701, SiteTech
Software Operation Manual, for instructions if
necessary.
2. Check the voltage calibration and adjust, if
necessary. See Section 3.7, Voltage Calibration.
Exporting Settings from a File
If a personal computer (laptop) and Kohlerr SiteTecht
software were used to create a controller settings file at
the time of generator set installation (when the controller
was known to be operating correctly), then SiteTech
software can be used to load the saved settings onto the
new controller. See TP-6701, SiteTech Software
Operation Manual, for instructions to export and import
controller settings.
Note: Load the old controller settings to the new
controller only if you are certain that the settings
are correct. Many generator set operation
problems can be caused by incorrect settings.
System Voltage Phases Phase Connection
120/240 1 Single Phase
120/208 3 Three-Phase Wye
127/220 3 Three-Phase Wye
120/240 3 Three-Phase Delta
277/480 3 Three-Phase Wye
220/380 3 Three-Phase Wye
230/400 3 Three-Phase Wye
240/416 3 Three-Phase Wye
Figure 3-8 Voltage and Phase Connections
Parameter Controller Menu SiteTech Group Settings
Genset Model Number
Genset Information Genset Info
38RCL, 48RCL, 48RCLA, or 60RCL
Genset Serial Number From nameplate; see Figure 3-6.
Fuel Type [
Genset System
Genset System
Configuration
Natural Gas or
Liquid Propane (LP)
Phase Connection SeeFigure3-8
Genset System Voltage From nameplate; see Figure 3-6.
Genset System Frequency 50 or 60 Hz
[ Fuel Type is available with controller firmware versions 4.5 or higher.
Figure 3-9 Controller Setup
