Kohler 38RCL User Manual

TP-6811 7/1694 Section 7 Disassembly/Reassembly
7.6 Alternator
The alternator is shown in Figure 7-5.
Note: Refer to the alternator service manual for
instructions to disassemble and reassemble the
alternator.
GM78543_B
3
2
5
1
4
1. Junction box top cover
2. Alternator adapter
3. Fan guard
4. Alternator assembly
5. Junction box
Figure 7-5 Alternator Components (see alternator Service Manual for details)
