TP-6137 5/034 Section 1 Specifications
1.5 Torque Specifications
Torque Specifications—Nm (ft. lbs.) 4EOZ/3.5EFOZ
Cylinder head nuts 30--33 (22--24.5)
Connecting rod nuts 30--33 (22--24.5)
Valve cover nuts 8--12 (6--9)
Main bearing plate nuts 30--33 (22--24.5)
Fuel pump nuts 30--33 (22--24.5)
Delivery valve holder--fuel pump 34--39 (25--29)
High pressure fuel pipe nut--fuel pump 18--22 (13.5--16)
High pressure fuel pipe nut--injector 25--30 (18.5--22)
Injector clamp nuts 8--12 (6--9)
Governor on crankshaft 55--60 (40.5--44.5)
Flywheel nut 216--226 (159.5--166.5)
Gear cover screws 34--38 (25--28)
Tappet block screws 8--10 (6--7.5)
Oil pump screws 16--20 (12--15)
Oil cooler screws 9--11 (6.5--8)
Banjo bolt on fuel pump 25--35 (18.5--26)
Body--injector nut 25--30 (18.5--22)
Starter screws 20 (15)
Flywheel/rotor hub nuts 25 (18.5)
Nut fixing the rotor 25 (18.5)
Stator screws 30 (22)
Alternator bracket screws 50 (37)
Engine bracket screws 50 (37)
