Kohler 5EFKOD Service Manual

TP-6774 2/14a14 Section 1 Specifications
1.2 Engine
Generator Model
6EKOD/
5EFKOD
(1 Phase)
9EKOZD/
7EFKOZD
(1 Phase)
11EKOZD/
9EFKOZD
(1 Phase)
11EKOZD/
9EFKOZD
(3 Phase)
Number of cylinders
3 4
Type
4 cycle, naturally aspirated
Engine block material
Cast iron with re-borable integral liners
Cylinder head material
Aluminum
Governor
Centrifugal, mechanical
Engine firing order (#1 cylinder on
flywheel end or alternator end)
1--3--2 1--3--4-2
Direction of rotation (as viewed from
flywheel)
Counterclockwise
Combustion system
Indirect injection
Bore x stroke, mm (in.)
75 x 77.6 (2.95 x 3.05)
Displacement L (CID)
1.028 (62.7) 1.372 (83.7)
Compression ratio
24.5:1
Max. power at rated rpm, HP 60/50 Hz
10.1/8.4 14.5/11.9 19.6/15.4
RPM 60/50 Hz
1800/1500
Lubrication system
Pressurized oil system with oil pump
Lube oil capacity, w/filter L (U.S. qts.)
2.5 (2.6) 3.4 (3.6)
Oil recommendation (API)
CD or CF class
Fuel recommendation (API)
Cetane No. 51 m in. Fuel with low sulphur content: API CF4, CG4 or
Fuel with high sulphur content API CF, CD, CE
Fuel shutoff solenoid
Electric
Fuel pump
Electric
Max. recommended fuel pump lift, m (ft.)
0.9 (3) 1.2 (4)
Battery voltage
12 volts
Battery charging module
10-amp
Battery recommendation (minimum)
650 CCA @ 0_F
Starter motor
2.5 kW, 12 volt
Recommended coolant
50% ethylene glycol; 50% clean, softened water
Coolant capacity, approx. L (U.S. qts.)
add 0.24 L (8 oz.) for coolant recovery tank
3 (3.2) 4.3 (4.5)
Thermostat, opening temp. _C(_F)
83--87 (181--188)
High exhaust temperature shutdown,
_C(_F)
102±2.8 (215±5)
Seawater inlet water line hose ID, mm (in.)
19 (0.75) with or without sound shield
Water cooled exhaust outlet hose ID,
mm (in.)
51 (2) with or without sound shield
Fuel inlet size
1/4 NPT with or without sound shield
Fuel return size
1/4 NPT with or without sound shield
Fuel injection pressure, bar 128--137
Intake/exhaust valve clearance (cold),
mm (in.)
0.20 (0.008)
Fuel pump static pressure, psi
4--8 (12-volt pump)
Pressure cap’s overpressure valve
opening pressure, bar
0.7
