FUEL SYSTEM

Injection pump non-return valve

Theexhaustunionhasanon-returnvalveA.Thepurposeofthisval-

veistoimprovetheinjectionphasebyexpellingtheairinthefueland

preventingitfrombeingsuckedinbythepumpduringtheintakepha-

se.Thisalsoensuresthattheenginestopspromptlyassoonasthe

stoppingdeviceisactivatedbymeansofthesolenoidvalve.

Outlet tting components for 315-350 EPA E 400-440 engines

1) Outlettting

2) BallØ1/8"

3) Threadeddowel

Donotcutthetubelongitudinallybecauseyoumightdamage

theunion.

Injection pump, Rilsan tube removal

CutnylontubeatA.

Removetheportionof the tube whichisstillconnected to the union

usingcommonpliers.Pinchthenylontubewithoutimpairingthesea-

lingpropertiesofunion(seegure).

Re-cyclethesamefeedingtube if theremaininglengthallowsit; re-

placeifnot.

Injection pump, Rilsan tube retting

TheoutlettubeismadeofnylontypeRilsan;itisconnectedtothesu-

itableinjectionpumpunionbymeansofspecialpliers(Ser.No.7104-

1460-023)andaplastic-headhammer(seegure).
