ELECTRICAL SYSTEM
24V, 9A alternator battery recharging curve
12V, 30A alternator battery recharging curve
Thetestwasconductedafterheatstabilizingat20°C.
The value of the current delivered in relation to the curve may be
subjectedtoavariationofbetween+10%and-5%.
Voltage regulator
12V,12A:forstandardalternatorswith3outputwires
12V,30A:for12V,20Aalternatorswith2outputwires
24V,9A:for24V,9Aalternatorswithtwooutputwires
Thetabsareindifferentsizestoprevent
incorrectconnections.
Tabdimensionsmm
Width Thickness
~ 6.35 0.80
R 9.50 1.12
+ 9.50 1.12
LE 4.75 0.50
0
/
0
6.35 0.80
W 4.75 0.50
KD 225_315_350_400_440 Workshop Manual_cod. ED0053029330_1° ed_ rev.00
