OTHER EQUIPMENT
DOOR OPEN LOCK
Use the door lock to fix the door in position after opening it.
1.
Push the door against the door catch (1).
The door is fixed to the catch.
2.
To release the door, move lever (2) inside the cab to the front of the cab.
The catch releases.
NOTICE
• When
keeping the door open, fix it securely to the
catch.
• Always close the door when traveling or performing
operations. If doors are left open, they may be broken.
• Keep the door locked open securely. The doors may
be closed by vibration.
SASH GLASS INTERMEDIATE LOCK
When working with the cab sash glass open, use this lock to
prevent the glass from chattering.
• When the lever is in FREE position (F), the glass can be
opened or closed.
• When the lever is in LOCK position (L), the glass is held in
position.
CAP AND COVER WITH LOCK
Use the starting switch key to open and close the locks on the caps and covers.
OPERATION EXPLANATION OF COMPONENTS
3-107
