5-49
35. ENGINE OIL PAN HEATER, COOLANT HEATER
To keep the engine warm and make it easy to start again when the engine has been stopped in cold
areas, an electric heater for the coolant and lubrication oil is available as an option.
1 Power supply : Prepare an AC, 3-phase, 230 V power supply with a capacity of at least 6 kW.
Provide also a breaker and fuses.
2 Insulated cable : Prepare a 3-core 5 – 8 mm
3
cable with a length of within 30 m.
3 Ground cable: Always ground the equipment.
4 Heater connector : There is a connector for the heater installed to the side face of the frame on the
left side of the engine.
REMARK
The customer should provide 1, 2, and 3.
Oil pan heater Coolant heater
Voltage 230 V 230 V
Capacity 600 W 1.5 kW
Current Approx. 2.6 A Approx. 6.5 A
