NAMES OF PARTS
* This camera is a sophisticated optical instrument. Care should be taken to keep these surfaces
clean. Please read the care and storage instructions in the back of this manual (p. 106).
Flash* (p. 28)
Self-timer lamp (p. 40)
Lens*
Shutter-release button
Recording-mode switch (p. 23)
Strap eyelet (p. 14)
USB-port / AV-out terminal
Microphone
Battery/Card-chamber door
(p. 16-20)
Indicator lamp**
LCD monitor*
Tripod socket
Controller
Display button (p. 30, 34)
Zoom lever (p. 24)
Menu button
Speaker
Main switch (p. 21)
Anti-Shake-on indicator (p. 47)**
Mode button (p. 33)
Delete/Flash button (p. 28, 34)
Cradle port*
Camera contacts*
Charging lamp
Cradle
