Technical Specifications
10
6 Technical Specifications
Table 4 lists the technical specifications
1
Table 4: Technical Specifications
of the 713 and the 714-05/714-10/714-15.
2
of the 713 and the 714-05/714-10/714-15
713 714-05/714-10/714-15
INPUT:
Video
1 composite 1Vpp/75Ω
on a BNC connector
1 RJ-45 CAT 5 connector (LINE IN)
Audio
1 stereo unbalanced
audio 4dBm/50kΩ on
two RCA connectors
OUTPUT: 1 RJ-45 CAT 5 connector (LINE
OUT)
Video
1 composite on a BNC connector
1Vpp/75Ω
Audio
1 stereo unbalanced audio
4dBm/50kΩ on two RCA
connectors
1 S/PDIF digital audio on an RCA
connector
VIDEO MAX. SIGNAL LEVEL: 1.4Vpp (terminated 75 Ω)
AUDIO MAX. SIGNAL LEVEL: 2.3Vpp
VIDEO BANDWIDTH (–3dB): 9MHz
AUDIO BANDWIDTH (–3dB): 20-20kHz
VIDEO S/N RATIO (unweighted): >55dB RMS
AUDIO S/N RATIO: >85db @1kHz
AUDIO CONVERSION: 48kHz/24bit
S/PDIF out >0.5V/75 Ω terminated
CONTROLS: Equalization; automatic and manual (+/–)
VIDEO COUPLING: Input: AC Output: DC
AUDIO COUPLING: Input: AC Output: DC
POWER SOURCE: 12 VDC 120mA 12 VDC 130mA
DIMENSIONS: 12cm x 6.9cm x 2.4cm (4.7" x 2.7" x 0.96") W, D, H
WEIGHT: 0.3kg (0.67lbs) approx. (each)
ACCESSORIES: Power supplies, mounting brackets
OPTIONS: RK-T1, RK-T3, 19 inch rack adapters
1 Specifications are subject to change without notice
2 Specifications are for 100m of CAT 5 UTP cable, unless otherwise specified
