Kramer ASPEN-32UFX User Manual

Kramer Electronics Ltd.
ASPEN-32UFX, ASPEN-1616UX, VS-8UFX – Technical Specifications
25
Technical Specifications
ASPEN
-32UFX
Inputs
1 Genlock
On a BNC connector
Outputs
1 Genlock (Loop)
On a BNC connector
Ports
32 Interchangeable12G
SDI/HD-SDI/SDI Video
(75Ω)
On BNC connectors (by default,
1 to 16 are set as inputs and 17
to 32 are set as outputs)
1 RS-232
On a 3-pin terminal block
1 Ethernet
On an RJ-45 connector
1 12V DC Primary Power
On a 2-pin connector
1 12V DC Redundant Power
On a 2-pin connector
ASPEN
-1616UX
Inputs
16 12G SDI/HD-SDI/SDI
Video (75Ω)
On BNC connectors
1 Genlock
On a BNC connector
Outputs
16 12G SDI/HD-SDI/SDI
Video (75Ω)
On BNC connectors
1 Genlock (Loop)
On a BNC connector
Ports
1 RS-232
On a 3-pin terminal block
1 Ethernet
On an RJ-45 connector
1 12V DC Primary Power
On a 2-pin connector
1 12V DC Redundant Power
On a 2-pin connector
VS-8UFX
Inputs
1 Genlock
On a BNC connector
Outputs
1 Genlock (Loop)
On a BNC connector
Ports
8 Interchangeable12G
SDI/HD-SDI/SDI Video
(75Ω)
On BNC connectors (by default,
1 to 4 are set as inputs and 5 to
8 are set as outputs)
1 RS-232
On a 3-pin terminal block
1 Ethernet
On an RJ-45 connector
1 AC Power
On an AC power connector
Video
Standards:
• 12G-SDI – SMPTE
ST-2082-1
• 3G-SDI – SMPTE 424M
• 6G — SMPTE ST–2081
• HD-SDI – SMPTE 292M
• SDI – SMPTE 259M/344M
Max Resolution
4K@60Hz (4:2:2)
Max Bandwidth
12Gbps
Extension Line
SD Signals
Up to 300m
1.5G HD Signals
Up to 200m
3G Signals
Up to 100m
6G Signals
Up to 100m
12G Signals
Up to 80m
Coupling
DC
User Interface
(ASPEN-32UFX,
ASPEN-1616UX)
Controls
Web pages and Protocol 3000
API via Ethernet and remote
RS-232
User Interface
(VS-8UFX)
Indicators
Port buttons LEDs, LCD display
Controls
Switching buttons, web pages
and Protocol 3000 API via
Ethernet and remote RS-232
