Krone Swadro 38 T User Manual

Operation
40
Pos: 83 /BA/B edienung /Schw ader/Schwadtuc h/Schwadform er/Schwadform er SW 38T/4 2T US @ 8\ mod_12193898125 01_78.doc @ 1 17531
8.4.4 To adjust the swath former lengthwise:
(Swadro 38 T, Swadro 42T)
SW46T033
5
4
3
6
Figure. 17
This adjustment is required for example if forage falls out at the front of the swath former.
To make the adjustment, loosen the coach bolts (6), move the swath former to the desired
position and tighten the coach bolts (6) again.
8.4.5 Height adjustment of the swath former:
The adjustment is required if forage falls under the swath former, for example, and is not
evened out by the working depth adjustment.
To do this:
• Loosen the coach bolts (6).
• Adjust the swath former in the oblong hole.
• Tighten the coach bolts (6).
Pos: 84 /BA/----- Seitenumbruch--- --- @ 0\mod _1196175311 226_0.doc @ 4165
