KSB Controlmatic E.2 User Manual

4 Description
11 of 24
Controlmatic E.2
Protective functions
▪ The pump is protected against dry running by simultaneous monitoring of
pressure and flow rate. If there is a lack of water, the automatic control unit
stops the pump and the red signal lamp (7) is lit.
4.6 Technical data
Table7: Performance data
Characteristic Value
Maximum operating pressure 10bar
Maximum amperage 10A
Fluid temperature 0 - +60°C
Maximum flow rate 10m
3
/h
Minimum flow rate 0,09m
3
/h
Minimum start-up pressure 1,5bar
4.7 Fluids handled
▪ Drinking water
▪ Service water
▪ Stormwater
▪ Fire-fighting water
▪ Cooling water
4.8 Displays and indicator lamps
Reset
Power
On
Failure
1
2
4
3
Fig.3: Indicator lamps
1 Ready for operation (green) 2 Fault (red)
3 Operation (yellow) 4 Reset button
