5 Installation at Site
13 of 24
Controlmatic E.2
CAUTION
Plastic threaded connections sealed with hemp
Stresses/strains and leaks in the plastic piping!
▷ Use Teflon tape for sealing.
Automatic control unit connection between pump and consumer installation
▪ Route connecting line between pump and automatic control unit.
▪ The diameter of the connecting line must at least equal the diameter of the
pump discharge line.
▪ Observe the direction of fluid flow (see arrow on automatic control unit).
5.4.2 Connecting the piping (wet installation)
DANGER
Automatic control unit submerged
Danger to life!
▷ Never submerge the automatic control unit.
▪ Use suitable connecting elements to connect the pump's discharge line directly to
the pump discharge nozzle.
▪ The diameter of the connecting line must at least equal the diameter of the
pump discharge line.
▪ Observe the direction of fluid flow (see arrow on automatic control unit).
▪ Always mount the automatic control unit in the vertical position.
▪ The automatic control unit has an integrated vent valve.
For submersible borehole pumps, the automatic venting function facilitates
priming of the pump under back pressure.
CAUTION
Plastic threaded connections sealed with hemp
Stresses/strains and leaks in the plastic piping!
▷ Use Teflon tape for sealing.
5.5 Electrical connection
Connection to power supply is effected by means of a 230V plug in accordance with
VDE0100.
Site-supplied fusing: 16A (max).
