6 Commissioning/Start-up/Shutdown
14 of 24
Controlmatic E.2
6 Commissioning/Start-up/Shutdown
6.1 Prerequisites for commissioning/start-up
Before commissioning/start-up of the system make sure that the following
requirements are met:
▪ The system has been properly connected to the electric power supply and is
equipped with all protection devices.
▪ All relevant VDE standards and/or regulations applicable in the country of use are
complied with.
6.2 Commissioning/Start-up
6.2.1 Commissioning
Dry installation
▪ Check whether the suction line of the pump is equipped with a suction strainer.
▪ Prime the pump and suction line with the fluid to be handled.
▪ Plug in the mains plug of the automatic control unit.
▪ Plug in the mains plug of the pump.
The green indicator lamp lights up permanently.
▪ Open a consumer installation.
If the red indicator lamp lights up, press and hold the red reset button until
priming of the system has been completed.
The red indicator lamp then extinguishes and the pump starts pumping.
Close the consumer installation.
If the red indicator lamp lights up again, repeat the above procedure.
▪ The pump stops after 5seconds.
The system will now start up automatically as soon as a consumer installation is
opened.
▪ Comply with the operating manual of the respective pump.
Wet installation
▪ Install the pump in the well or sump.
The pump fills with the fluid to be handled.
▪ Plug in the mains plug of the automatic control unit.
▪ The green indicator lamp lights up permanently.
▪ Open a consumer installation.
If the red indicator lamp lights up, press and hold the red reset button until
priming of the system has been completed.
The red indicator lamp then extinguishes and the pump starts pumping.
Close the consumer installation.
If the red indicator lamp lights up again, repeat the above procedure.
▪ The pump stops after 5seconds.
The system will now start up automatically as soon as a consumer installation is
opened.
▪ Comply with the operating manual of the respective pump.
6.2.2 Setting the start-up pressure
The automatic control unit is factory-set to 1.5bar.
This pressure setting cannot be changed.
NOTE
The head between the highest consumer and the pump must always be lower than
the pressure set at the automatic control unit.
