BULB FOR THE TAILLIGHT:
Remove the bulb socket [2] from the housing and pull the bulb out of the socket. Insert a
new bulb and press the bulb socket all the way into the taillight housing.
Mount the seat.
MAINTENANCE WORK ON CHASSIS AND ENGINE »
59
Replacing the brake light and taillight bulbs
NOTE:
Only mount red light bulbs in a smoked brake tail light.
Remove the seat.
BULB FOR BRAKE LIGHT:
Turn the bulb socket [1] approx. 30° in a counterclockwise direction and pull it out of the
taillight housing. Slightly press in the bulb, turn approx. 30° in a counterclockwise direc-
tion and remove it from the socket.
Proceed in the reverse order to mount a new bulb.
1
2
3
Replacing the flasher bulbs
Remove the screw on the back of the turn signal, carefully fold the lens [3] towards the
motorcycle and remove.
Slightly depress the bulb, turn it approx. 30° counterclockwise and pull it out of the socket.
To mount the lamp reverse the worksteps indicated above.
