Clutch lever
The clutch lever [1] is fitted on the left hand side of the handle bar. The adjusting screw [A]
is used to change the original position of the clutch lever (see maintenance work on chas-
sis and engine).
The clutch is hydraulically actuated and adjusts itself automatically.
Hand brake lever
The hand brake lever [2] is mounted on the handlebar on the right and actuates the front
wheel brake.The adjusting screw [B] is used to change the original position of the hand brake
lever (see maintenance work on chassis and engine).
OPERATION INSTRUMENTS »
7
B
2
1
A
